MYRRA 47163 Electronic Transformer
The 47000 series electronic transformers are switched-mode power supplies based on flyback topology, designed for power levels below 5W. They offer high efficiency, low standby power, and wide input voltage ranges (85-265V AC/DC). Suitable for replacing traditional linear transformers, fuse, bridge rectifier, and filtering capacitors, these transformers are ideal for industrial, domestic, and consumer electronics. They feature reinforced insulation, open-circuit and short-circuit protection, thermal shutdown, and meet strict safety and EMC standards, ensuring reliable and energy-efficient operation in various applications.
MYRRA 47163 Electronic Transformer Specifications:
- Input Voltage Range: 85-265V AC / 85-370V DC
- Input Frequency: 47-440 Hz
- Output Voltage: 3.3V DC (regulated), 3.2V-5V (non-regulated), or dual outputs with 3-5W power
- Output Voltage Accuracy: +2% for regulated, +5% for non-regulated
- Line Voltage Variation: +0.3% (regulated), +3% (non-regulated)
- Load Voltage Variation: +0.5% (regulated), +30% (non-regulated)
- No Load Power Consumption: <200mW (regulated), <300mW (non-regulated)
- Operating Temperature: -25°C to +85°C, Storage -40°C to +85°C
- Isolation Voltage: 4000 Vac between input/output
- Protection: Reverse insulation, short circuit, thermal shutdown
- Protocol Compliance: EN 60950, EN 60335, EN 61558-2-17, UL Listed and UL 94-V0 plastics
Buy the Myrra Series 47000 Electronic Transformer: 47163
Discover the energy-efficient and reliable Myrra Series 47000 electronic transformer, designed for low-power AC/DC applications. Its wide input voltage range of 85-265V AC/DC and output power up to 5W make it ideal for replacing traditional linear transformers, fuse, bridge rectifier, and filtering capacitors. Ensuring high safety standards with reinforced insulation and UL listing, these transformers provide protection against short circuits and overheating. Perfect for industrial, domestic, and consumer electronics, they deliver consistent performance while reducing energy consumption and footprint without redesigning your PCB.
Order your Myrra Series 47000 electronic transformer today and ensure reliable, energy-efficient power supply for your low-power electronic applications.
Frequently Asked Questions
Where can I buy MYRRA 47163?
You can click on the BUY or RFQ button to purchase 47163 from an authorized MYRRA distributor.
How do I troubleshoot issues or seek technical support for part 47163?
You can download the 47163 datasheet or visit the MYRRA website for support.
Who is the manufacturer of 47163?
MYRRA
