MYRRA 47164 Electronic Transformer
The 47000 series electronic transformers are high-efficiency switched mode power supplies suitable for power applications under 5W. They utilize flyback topology, offering energy savings, low standby power, and broad input voltage compatibility from 85V to 265V AC or 85V to 370V DC. These transformers replace traditional linear transformers, fuses, bridge rectifiers, and filtering capacitors, providing reliable switching solutions for industrial, telecom, and consumer electronics. They meet safety and EMC standards, feature thermal shutdown, short circuit protection, and are compatible with Class II insulation requirements, making them ideal for energy-efficient, low-profile power supply needs.
MYRRA 47164 Electronic Transformer Specifications:
- Input voltage range: 85 to 265 Volts AC, 85 to 370 Volts DC
- Input frequency: 47 to 440 Hz
- Output voltage accuracy (full load): +2% for regulated, +5% for non-regulated models
- Line voltage variation: +0.3% for regulated, +3% for non-regulated
- Load voltage variation: +0.5% for regulated, +30% for non-regulated
- No load input power: <200mW for regulated, <300mW for non-regulated
- Output power: 2.5W to 5W depending on model
- Isolation test voltage: 4000 Vac input/output and output/output
- Operating temperature: -25°C to +85°C
- Storage temperature: -40°C to +85°C
- Protection: integrated fusible resistor, automatic restart for short circuit, thermal shutdown with recovery
- Dimensions: Similar footprint as EI30 transformer, with 4 to 6 pins depending on configuration
- Certifications: UL listed components, meets EN 60950, EN 60335, EN 61558-2-17
- EMC compliance: EN 55014-1, EN 55022 class B, EN 55014-2, EN 61000-4-x
Buy the Buy 47000 Series Electronic Transformers Part Number 47164 Online
Enhance your electronic projects with the high-efficiency 47000 series transformers. Suitable for power applications below 5W, these transformers feature broad input voltage compatibility, low standby power, and advanced safety standards. Perfect for industrial, telecom, and consumer electronics, they are designed to replace traditional linear transformers, fuses, and rectifiers easily without PCB redesign. Benefit from reliable short circuit and thermal protections, UL certification, and compliance with energy regulations. Purchase online now for quick delivery and trusted performance in your low-power switching applications.
Order your 47000 series electronic transformer with switch mode power supply today and ensure reliable, energy-efficient power for your low-wattage applications.
