MYRRA 47212 Industrial Power Supply
This regulated 10W single-output power supply offers a compact PCB mount design suitable for various applications requiring 3.3V to 24V DC output. It features high efficiency, low standby power consumption under 0.1W, and robust safety certifications including IEC, UL, and CE standards. With an input voltage range of 85VAC-265VAC or 120VDC-370VDC, it provides reliable performance from -25°C to +85°C with excellent EMC compliance, making it ideal for industrial, medical, or consumer electronics needing stable and efficient power conversion.
MYRRA 47212 Industrial Power Supply Specifications:
- Output Power: 10W
- Output Voltage Range: 3.3VDC - 24VDC
- Input Voltage Range: 85VAC - 265VAC / 120VDC - 370VDC
- Input Frequency: 47Hz - 63Hz
- Efficiency: >82% @ 230VAC, >80% typical
- Standby Power Consumption: < 0.1W
- Operating Temperature: -25°C to +85°C
- Storage Temperature: -40°C to +85°C
- Dimensions: 48.0mm (L) x 40.0mm (W) x 26.5mm (H)
- Material: UL 94-V0 plastic and resin
- Certifications: IEC/EN61000-4 series, UL, CE, VDE, ENEC
- Protection: Short circuit, over-temperature, overload protection
- Dielectric Strength: 4000Vac primary to secondary
- EMC Compliance: EN55014, EN55022, FCC Part 15 Class B
- MTBF: 200,000 hours at 230VAC, 60°C
Buy the Brand Series Power Supply: 47212
Purchase the Brand Series 47212 regulated power supply online today and enjoy a compact, highly efficient device perfect for demanding industrial and electronic applications. Featuring a broad input voltage range, low standby power, and comprehensive safety and EMC certifications, this power supply ensures optimal performance and reliability. Its robust design withstands operation from -25°C to +85°C, and it includes protections against short circuits, over-temperature, and overload, making it an ideal choice for engineers and technicians seeking dependable power conversion for diverse projects.
Order your Brand Series 47212 power supply today and ensure reliable, efficient power with excellent safety and EMC standards for your projects.
