MYRRA 48022 Industrial Power Module
This compact, encapsulated power supply offers reliable 3.3V to 24V DC output through a PCB mount design, suitable for industrial automation, control systems, and electronic devices. It features an input voltage range of 85VAC to 265VAC or 120VDC to 370VDC, with high efficiency, low standby power under 0.15W, and robust safety and EMC compliance including IEC and UL standards. Its small footprint allows easy PCB integration without redesign, making it ideal for industrial, instrumentation, and embedded applications where space-saving is critical.
MYRRA 48022 Industrial Power Module Specifications:
- Input Voltage: 85-266Vac or 120VDC-370VDC
- Input Frequency: 47-63Hz
- Input Current: Max 0.15A at 85Vac~285Vac
- Output Voltage Range: 3.3VDC to 24VDC
- Output Voltage Accuracy: ±4.5%
- Output Voltage Line Regulation: ±2.0%
- Output Voltage Load Regulation: ±5%
- Ripple & Noise: Max 180mVp-p at rated load
- Efficiency: Meets Energy Star & EC Code of Conduct
- Standby Power Consumption: Max 0.15W
- Hold Up Time: Min 5ms at full load
- Turn On Delay: Max 3s
- Over Current & Short Circuit Protection: Auto-recovery
- Over Temperature Protection: Thermal shutdown at 140°C
- Operating Temperature: -25°C to +70°C
- Storage Temperature: -40°C to +85°C
- Safety & EMC Standards: IEC/EN 60950, UL, CE, EN55032, EN55014, FCC Part 15B
- Dimensions: Small, encapsulated design, typical weight 16 grams
Buy the Innovative 48022 U– Reliable Power Supply for Industrial Applications
Order the 48022 power supply online today to ensure your industrial automation, embedded systems, and control applications are powered by a reliable, energy-efficient component. Its compact design fits easily on your PCB, enabling space-saving integration without redesign. With high safety compliance, low standby power, and protection features like short circuit and thermal shutdown, it guarantees durability and safety in demanding environments. Purchase now and enhance your device performance with a trusted power solution designed for industrial use.
Get 48022 power supply today—compact, efficient, and built for industrial control systems and embedded electronics.
