MEGGER BD59090US High-Current Micro-ohmmeter
This portable high-current resistance tester delivers up to 240 A for measuring the resistance of high-current links. Featuring DualGround technology, it keeps both sides grounded during testing for safety, speed, and workflow efficiency. It offers auto-ranging from 1 microohm to 1000 milliohms, using ultra capacitor technology to generate high currents. The device stores 190 test results and wirelessly transfers data via Bluetooth to a PC. Lightweight at only 2.2 pounds (1 kg), it includes Kelvin clamps and probes for accurate 4-wire Kelvin resistance measurements, ideal for circuit breaker testing, busbars, connectors, and industrial maintenance.
MEGGER BD59090US High-Current Micro-ohmmeter Specifications:
- Operation Temperature: -2°C to +50°C
- Storage Temperature: -20°C to +70°C
- Relative Humidity: 5%-95% non condensing
- Power Supply: Five AA 2700 mAh NiMH batteries, recharge <12h, typical recharge 3h
- Battery Charger: 100-250 V AC, 50/60 Hz, protection against incorrect/bad temperature
- Dimensions: 217 x 104.7 x 41 mm
- Weight: 2.2 lbs (1.0 kg) instrument only, 11 lbs (6.0 kg) with accessories
- Measurement Range: 0-999 pQ (microohms), 1.09-99.9 mQ (milliohms)
- Resolution: 0.01 mQ to 1 mQ depending on range
- Output Voltage Max: 2.5 VDC
- Current Generation: selectable 50A / 100A, max resistance <2 mQ
- Calibration: Field calibration supported
- Protection: Against wrong battery type, low/high temperature
Buy the Megger MOM2 – Reliable High-Current Micro-ohmmeter for Industrial Applications
Purchase the Megger MOM2 handheld micro-ohmmeter online today and enhance your electrical testing capabilities. This portable device measures high current resistances up to 240A with safety and accuracy. Features include DualGround technology for safe testing with both sides grounded, Bluetooth data transfer for easy results management, Kelvin probes for precise 4-wire resistance measurements, and a lightweight design for field use. Ensure your high-current connections and circuit breakers are functioning properly, reducing failure risk and improving operational safety with this advanced testing instrument available for quick online ordering.
Order your Megger MOM2 handheld high-current micro-ohmmeter today and achieve precise, safe resistance measurements in demanding electrical environments.
Frequently Asked Questions
Where can I buy MEGGER BD59090US?
You can click on the BUY or RFQ button to purchase BD59090US from an authorized MEGGER distributor.
How do I troubleshoot issues or seek technical support for part BD59090US?
You can download the BD59090US datasheet or visit the MEGGER website for support.
Who is the manufacturer of BD59090US?
MEGGER
