Microchip Technology TC1411CPA MOSFET Driver
The TC1411/TC1411N are high-speed, 1A CMOS MOSFET drivers designed for switching power supplies, line drivers, and relay applications. They feature latch-up protection, ESD protection up to 2.0 kV, and support wide input voltages from 4.5V to 16V. Capable of charging 1000pF loads in 25ns with matched delay times, these drivers are housed in space-efficient 8-pin MSOP packages. They withstand negative inputs and reverse currents, making them robust for various demanding electronic switching tasks.
Microchip Technology TC1411CPA MOSFET Driver Specifications:
- Supply Voltage: 4.5V to 16V
- Peak Output Current: 1A
- Input Voltage (High): 2.0V min
- Input Voltage (Low): 0.8V max
- Output Resistance: 8Ω at 16V, 10-14Ω at 25°C to 85°C
- Maximum Junction Temperature: +150°C
- Power Dissipation: 0.5 to 1.0 mA supply current at typical conditions
- Electrostatic Discharge (ESD): 2.0 kV (HBM), 400V (MM)
- Delay Time: 30 ns typical
- Capacitive Load Drive Capability: 1000 pF in 25 ns
- Temperature Range: -40°C to +125°C (depending on version)
- Package Types: 8-pin MSOP, PDIP, SOIC
- Package Dimensions: MSOP width 3.0 mm, length 3.0 mm, height 1.10 mm
- Pinout: same as TC1410/TC1412/TC1413, with supply, input, output, and ground pins
- Low supply current: 500 pA (logic '1'), 100 pA (logic '0')
- Protection: Full ESD protection, latch-up resistant, accepts reverse currents up to 500 mA
Buy the Buy Microchip TC1411 Part Number TC1411CPA Online
