NMB TECHNOLOGIES 4715TS12TB5AA00 Cooling Fan
The 4715TS-12T-B5A-A00 axial fan is ideal for cooling electronic and industrial equipment, featuring a steel impeller, aluminum housing, and ball bearings for durability. Operating at 115VAC, it delivers high airflow with speeds of 2600 and 3100 RPM, consuming 17 and 21 watts respectively. The fan's aluminum casing with black finish ensures reliable heat dissipation, with static pressures of 0.352 and 0.4 inches H2O. It includes UL3266 compliant 22AWG lead wires and a Faston #110 connector, with thermal protection, insulation resistance over 10MΩ, and suitable for temperatures from -10°C to 60°C, ensuring efficiency and safety in cooling applications.
NMB TECHNOLOGIES 4715TS12TB5AA00 Cooling Fan Specifications:
- Motor Type: Shaded Pole Induction Motor
- Housing Material: Aluminum with Black Finish
- Impeller Material: Steel
- Bearing Type: Ball Bearings
- Voltage: 115V AC
- Frequency: 50/60Hz
- Speed: 2600/3100 RPM
- Power Consumption: 17/21W
- Static Pressure: 0.352/0.4 inches H2O
- Air Flow: 88.0 CFM
- Inlet/Outlet Diameter: 1.49 inches
- Thermal Protection: Yes
- Insulation Resistance: Over 10MΩ at DC 500V
- Operating Temperature Range: -10°C to 60°C
- Storage Temperature Range: -40°C to 70°C
- Lead Wire: UL 3266 compliant 22AWG
- Connector: Faston #110 or equivalent
Buy the NMB Series 4715TS Cooling Fan: 4715TS12TB5AA00
Purchase the NMB cooling fan online today to ensure efficient heat dissipation in your electronic or industrial equipment. Featuring a robust steel impeller, aluminum casing with a sleek black finish, and ball bearings for extended lifespan, this fan operates at 115VAC with speeds of 2600 and 3100 RPM. It consumes minimal power while providing high airflow and static pressure, making it ideal for heat dissipation. Equipped with UL compliant wiring, thermal protection, and capable of functioning in diverse temperature environments, this fan guarantees reliable performance and safety in demanding cooling applications.
Get NMB 4715TS12TB5AA00 today—built for precision cooling and long-lasting durability in electronic and industrial applications.
