NVENT HOFFMAN CSD242010W Control Enclosure
The CSD242010W is a CONCEPT™ single-door wall-mounted enclosure, featuring a clear polycarbonate window and designed for machine control applications. It offers a streamlined design with flush quarter-turn latches, a durable ANSI 61 grey polyester powder finish, and a three-point latch system for enclosures wider than 42 inches. The enclosure has seamless welded seams, ground smooth for a finished appearance, and corner-formed doors. It includes easy-to-remove hinge pins with built-in captivation clips, high-torque thread-less door fasteners, and a minimum-width body flange for maximum door opening (210°). External formed body flanges, panel mounting studs for optional accessories, and mounting holes for external wall brackets are provided. The door features a hidden hinge system for aesthetic appeal, a seamless foam-in-place gasket, and provisions for an optional high-impact thermoplastic data pocket. Enclosures over 30 inches wide have a door alignment device, with four hinges on 60-inch-high units. It is rated IP66 and complies with NEMA/EEMAC standards 4, 12, and 13, making it suitable for harsh industrial environments.
NVENT HOFFMAN CSD242010W Control Enclosure Specifications:
- Material: Steel with polyester powder finish
- Finish: ANSI 61 grey or RAL 7035 textured light gray
- Type: Single-door with clear polycarbonate window
- Rating: IP66, NEMA 4, 12, 13
- Construction: Seamlessly welded, ground smooth seams
- Door System: Hidden hinge, four hinges on 60-inch units, easy removal
- Latch: Quarter-turn with foam-in-place gasket, three-point on wider models
- Door Opening: Up to 210° with body flange trough to exclude liquids
- Panel Mounting: Studs on body for accessories, external mounting holes
- Provisions: Thermoplastic data pocket, door alignment device on over 30-inch wide units
Buy the Hoffman Series CONCEPT Enclosures: IP66 Polycarbonate Window Control Box: CSD242010W
Order the Hoffman CONCEPT CSD242010W wall-mounted control enclosure online today and benefit from rugged IP66 protection, clear polycarbonate window, seamless construction, and flexible mounting options. Perfect for industrial control applications, it features easy installation, a durable finish, and provisions for accessories like data pockets and wall brackets. Secure your sensitive electronics against dirt, water, and contaminants while enjoying hassle-free ordering with fast delivery. Protect your investments and ensure optimal performance by purchasing this high-quality enclosure online now.
Buy Hoffman CONCEPT CSD242010W wall-mounted enclosure now and ensure reliable protection for your electronic components in harsh industrial environments.
Frequently Asked Questions
Where can I buy NVENT HOFFMAN CSD242010W?
You can click on the BUY or RFQ button to purchase CSD242010W from an authorized NVENT HOFFMAN distributor.
How do I troubleshoot issues or seek technical support for part CSD242010W?
You can download the CSD242010W datasheet or visit the NVENT HOFFMAN website for support.
Who is the manufacturer of CSD242010W?
NVENT HOFFMAN
