NVENT HOFFMAN TFP61 Cooling Fan
The TFP61 is a 6-inch cooling fan designed for reliable operation in enclosure cooling applications. It operates at 115VAC and features a composite grille for protection. The fan incorporates ball bearing construction and split capacitor motors that are thermally protected to prevent premature failure. It includes a washable foam filter (Type-1) or disposable filter (Type-12), and its dynamically balanced impellers are molded from polycarbonate material. The fan has lead wires with 1/2 inch (12 mm) stripped ends for easy connection. It offers airflow ranging from 45 CFM (76 m³/h) to 215 CFM (365 m³/h) and can operate continuously at temperatures up to 158°F (70°C). Designed for up to 50,000 hours of maintenance-free operation, it is suitable for automotive, industrial, and HVAC applications and comes with a composite air plenum, finger guard, grille, and air filter.
NVENT HOFFMAN TFP61 Cooling Fan Specifications:
- Size: 6 inches
- Rated Voltage: 115 VAC
- Frequency: 50/60 Hz
- Nominal Current Max: 75.1 Amps
- Power Consumption Max: 36/32 Watts
- Airflow: 45 to 215 CFM (76 to 365 m³/h)
- Maximum Operating Temperature: 158°F (70°C)
- Construction: Ball bearings, split-capacitor motor, polycarbonate impeller
- Lead wires: Stripped ends 1/2 inch (12 mm)
- Durability: Up to 50,000 hours of continuous operation
- Includes: Fan, air filter, composite plenum, finger guard, grille
- Certifications: UL 508A, CSA, CE
- Finish: Brushed stainless steel grille or black ABS plastic grille
Buy the Buy PENTAIR TFP61 Part Number TFP61 Online
Enhance your enclosure cooling with the high-quality PENTAIR TFP61 fan. Designed for reliability, its thermally protected split-capacitor motor ensures long life, operational up to 50,000 hours. Equipped with a composite grille and washable foam filter, it provides efficient airflow from 45 to 215 CFM, suitable for industrial, automotive, or HVAC applications. Easy connection with stripped lead wires, this durable fan combines performance and ease of installation. Order online now to upgrade your enclosure cooling system effortlessly.
Order your PENTAIR TFP61 series 6-inch cooling fan today and ensure reliable enclosure cooling for industrial, automotive, or HVAC projects.
Frequently Asked Questions
Where can I buy NVENT HOFFMAN TFP61?
You can click on the BUY or RFQ button to purchase TFP61 from an authorized NVENT HOFFMAN distributor.
How do I troubleshoot issues or seek technical support for part TFP61?
You can download the TFP61 datasheet or visit the NVENT HOFFMAN website for support.
Who is the manufacturer of TFP61?
NVENT HOFFMAN
