Nichicon UKA1C221MED1TD Aluminum Electrolytic Capacitors
High-quality aluminum electrolytic capacitors suitable for audio equipment, operating at -55°C to +105°C with rated voltages from 6.3V to 50V. Featuring low leakage current, excellent stability at low temperatures, and long endurance of 2000 hours at 105°C. Ideal for high-grade audio and electronic applications, these capacitors follow RoHS standards and provide reliable performance with precise capacitance tolerance. They are available in various capacitance values, with specific dimensions and ratings to meet diverse circuit requirements.
Nichicon UKA1C221MED1TD Aluminum Electrolytic Capacitors Specifications:
- Category Temperature Range: -55°C to +105°C
- Rated Voltage Range: 6.3V to 50V
- Capacitance Range: 22 to 22000μF
- Capacitance Tolerance: +20% at 120Hz, 20°C
- Leakage Current: ≤ 0.03CV or 4μA after 1 min, ≤ 0.01CV or 3μA after 2 min
- Tan δ (loss angle): MAX 0.30 at 63V, decreasing to MAX 0.14 at 50V
- Stability at Low Temp: Z−25°C/Z+20°C ratio MAX 5 (from 10−16V to 10−25V)
- Endurance: 2000 hours at 105°C with leakage current within initial limits
- Shelf Life: 1000 hours at 105°C, meets specifications after voltage treatment
- Physical Size and Dimensions: Vary depending on capacitance, for example, 22μF 5x11mm, 2200μF 12.5x20mm
- Frequency Coefficient: 0.75 to 1.35 depending on capacitance, rated ripple current varies accordingly
Buy the Nichicon Series KT Aluminum Electrolytic Capacitors: UKA1C221MED1TD
Purchase your Nichicon Series KT aluminum electrolytic capacitor today and benefit from high-quality, durable performance designed for audio and electronic applications. With a wide temperature range from -55°C to +105°C, rated voltages up to 50V, and capacitance values spanning 22μF to 22000μF, these capacitors ensure long-term stability and low leakage current. Ideal for high-grade audio equipment, power supplies, and circuit filtering, they meet RoHS standards for environmentally conscious manufacturing. Enjoy fast delivery and secure online ordering to upgrade your designs efficiently.
Order your Nichicon Series KT aluminum electrolytic capacitor today and enhance your audio and electronic projects with reliable, high-performance components.
Frequently Asked Questions
Where can I buy Nichicon UKA1C221MED1TD?
You can click on the BUY or RFQ button to purchase UKA1C221MED1TD from an authorized Nichicon distributor.
How do I troubleshoot issues or seek technical support for part UKA1C221MED1TD?
You can download the UKA1C221MED1TD datasheet or visit the Nichicon website for support.
Who is the manufacturer of UKA1C221MED1TD?
Nichicon
