Nichicon UKA1C471MPD1TD Aluminum Electrolytic Capacitors
High-quality aluminum electrolytic capacitors suitable for audio equipment with a high temperature rating of 105°C. These capacitors feature selected materials to produce superior sound quality, with a wide capacitance range from 22 to 22000 microfarads and rated voltages between 6.3V and 50V. They meet RoHS standards and offer excellent stability at low temperatures, long endurance life of 2000 hours at 105°C, and are marked for easy identification. Ideal for audio applications requiring reliable, durable, and high-performance capacitors with precise tolerances.
Nichicon UKA1C471MPD1TD Aluminum Electrolytic Capacitors Specifications:
- Category Temperature Range: -55 to +105°C
- Rated Voltage Range: 6.3 to 50V
- Rated Capacitance Range: 22 to 22000μF
- Capacitance Tolerance: +20% at 120Hz, 20°C
- Leakage Current: ≤ 0.03CV or 4μA after 1 minute
- Leakage Current (2 mins): ≤ 0.01CV or 3μA
- Tang of Loss Angle (tan δ): MAX 0.30 at 63V, decreasing at higher voltages
- Stability at Low Temperature: Z -25°C to +20°C, MAX tan δ 0.26
- Endurance: 2000 hours at 105°C with leakage current within initial limits
- Shelf Life: 1000 hours at 105°C, maintaining specifications
- Dimensions vary with capacitance; for example, 470μF 6.3x11mm, 2200μF 12.5x20mm, 15000μF 16x35.5mm
Buy the Buy Aluminum Electrolytic Capacitors Part Number UKA1C471MPD1TD Online
Elevate your audio systems with high-temp aluminum electrolytic capacitors designed for superior sound quality and durability. With voltage ratings from 6.3V to 50V and capacitance up to 22000μF, these ROHS compliant capacitors provide exceptional stability, low leakage, and long-lasting endurance. Perfect for professional audio equipment, power supplies, and electronic circuits requiring high reliability, these capacitors are marked for easy identification and feature a wide temperature range for various environments. Order online now for fast delivery and performance assurance.
Buy Aluminum Electrolytic Capacitors UKA1C471MPD1TD now and experience unmatched reliability and audio performance with long-life stability.
Frequently Asked Questions
Where can I buy Nichicon UKA1C471MPD1TD?
You can click on the BUY or RFQ button to purchase UKA1C471MPD1TD from an authorized Nichicon distributor.
How do I troubleshoot issues or seek technical support for part UKA1C471MPD1TD?
You can download the UKA1C471MPD1TD datasheet or visit the Nichicon website for support.
Who is the manufacturer of UKA1C471MPD1TD?
Nichicon
