Nichicon UKA1V220MDD1TD audio electrolytic capacitor
High-quality aluminum electrolytic capacitors designed for audio equipment use, capable of operating within a temperature range of -55°C to +105°C. These capacitors feature a rated voltage between 6.3V and 50V and capacitance values from 22uF to 22000uF, offering stability at low temperatures and excellent endurance over 2000 hours at 105°C. Suitable for high-grade audio applications, they are RoHS compliant, with precise leakage current and tangent of loss angle specifications, ideal for power filtering and signal smoothing in sophisticated audio gear.
Nichicon UKA1V220MDD1TD audio electrolytic capacitor Specifications:
- Category Temperature Range: -55°C to +105°C
- Rated Voltage Range: 6.3V to 50V
- Capacitance Range: 22uF to 22000uF
- Capacitance Tolerance: +20% at 120Hz, 20°C
- Leakage Current: ≤ 0.03CV or 4μA after 1 min (whichever is greater)
- Leakage Current (after 2 min): ≤ 0.01CV or 3μA
- Rated voltage (V): 63, 70, 25, 35, 50
- Tan δ (max): 0.30 at 63V, 0.26 at 70V, 0.22 at 25V, 0.18 at 35V, 0.16 at 50V
- Z-25°C / Z+20°C: 5 / 4 / 3 / 2 / 2 / 2
- Capacitance Change: Within +20% after 2000 hours at 105°C
- Endurance: 2000 hours at 105°C with leakage current ≤ initial value
- Shelf Life: 1000 hours at 105°C, then voltage treatment per JIS C 5101-4
- Marking: Black print on pearl blue sleeve
- Case Size: Ranges from 5x11mm to 18x40mm depending on capacitance
- Ripple Current: 120Hz at 105°C; values increase with frequency
- Frequency Coefficient: 0.75 to 1.15 depending on capacitance
Buy the Nichicon UKA1V220MDD1TD – Reliable Aluminum Electrolytic Capacitors for Industrial Applications
Purchase the Nichicon aluminum electrolytic capacitor today to ensure high-performance audio and power supply applications. These capacitors operate efficiently over a broad temperature range from -55°C to +105°C and provide stable capacitance values up to 22000μF. With excellent endurance at 105°C for 2000 hours and low leakage current, they are ideal for high-grade audio equipment, power filtering, and smoothing circuits. RoHS compliant, these capacitors guarantee quality, durability, and reliability for professional electronic designs.
Buy Nichicon UKA1V220MDD1TD now and experience unmatched reliability and performance for your audio and power supply projects.
Frequently Asked Questions
Where can I buy Nichicon UKA1V220MDD1TD?
You can click on the BUY or RFQ button to purchase UKA1V220MDD1TD from an authorized Nichicon distributor.
How do I troubleshoot issues or seek technical support for part UKA1V220MDD1TD?
You can download the UKA1V220MDD1TD datasheet or visit the Nichicon website for support.
Who is the manufacturer of UKA1V220MDD1TD?
Nichicon
