OEP--OXFORD-ELECTRICAL-PRODUCTS- Z1612E Line Isolation Transformer
This 600:600 line isolation and matching transformer is designed for V.34 applications, offering low distortion and high-performance electrical characteristics. Resin-encapsulated in UL94-V0 flame-retardant cases, it provides excellent isolation with a longitudinal voltage of 3.5kV RMS, and features low insertion loss of 1.5dB at 2kHz, and a return loss of -20dB over 200Hz-4kHz. Suitable for telephone line diversion and line matching, it ensures compliance with BS6305, making it ideal in telecommunications and switching systems with minimal signal distortion and high reliability.
OEP--OXFORD-ELECTRICAL-PRODUCTS- Z1612E Line Isolation Transformer Specifications:
- Line ratio: 600:600
- Isolation Voltage: 3.5kV RMS / 5kV peak
- Insertion Loss: 1.5dB @ 2kHz
- Return Loss: -20dB @ 200Hz-4kHz
- Saturation Voltage: 10V RMS @ 50Hz, 65V peak
- Distortion: 0dB / 600Ω, f=450Hz, 2nd harmonic -88dBm
- Linearity: <0.03% THD 300Hz - 4kHz @-10 dBM/600Ω
- dc Resistance Primary: Typically 50Ω ±10%, Secondary: Typically 60Ω ±10%
- Leakage Inductance: Approximately 4mH
- Dimensions: Height 15mm, Width 18mm, Depth 18mm
- Encapsulation: Resin, UL94-V0 rated
- Conforms to: EN60950, EN41003, BS6305
- Certification: BABT
Buy the Walters Series Z1612E Line Isolation Transformer: Z1612E
Purchase the Walters Z1612E line isolation transformer online today and ensure your telecommunications setup is reliable, compliant, and low distortion. Designed with UL94-V0 flame-retardant case, it provides excellent electrical isolation, minimal insertion loss, and high voltage withstand capability. Ideal for V.34 applications and line matching, this transformer guarantees high performance and safety standards. Simplify your installation, ensure compliance with industry regulations, and enjoy durable, high-quality signal transmission with this advanced transformer, perfect for demanding telecom and switching environments.
Buy Walters Z1612E line isolation transformer now and experience unmatched reliability and performance for high-quality telecommunications systems.
Frequently Asked Questions
Where can I buy OEP--OXFORD-ELECTRICAL-PRODUCTS- Z1612E?
You can click on the BUY or RFQ button to purchase Z1612E from an authorized OEP--OXFORD-ELECTRICAL-PRODUCTS- distributor.
How do I troubleshoot issues or seek technical support for part Z1612E?
You can download the Z1612E datasheet or visit the OEP--OXFORD-ELECTRICAL-PRODUCTS- website for support.
Who is the manufacturer of Z1612E?
OEP--OXFORD-ELECTRICAL-PRODUCTS-
