OMEGA PX3005STBPIPE Differential Pressure Transmitter
The PX3005-DIFF pressure transmitter features a robust stainless-steel enclosure with IP67 rating, suitable for washdown environments. It offers rangeability from -100 to 100% FS with high accuracy of 0.075%. This device includes a backlit LCD display for process visualization, configurable output from 4 to 20 mA, and nineteen selectable measurement units. Engineered for industrial applications, it ensures reliable, precise pressure measurement in hydraulic, process automation, and tank level systems with long-term stability and vibration resistance.
OMEGA PX3005STBPIPE Differential Pressure Transmitter Specifications:
- Power Supply: 10.5 to 55VDC
- Output Signal: 4 to 20mA, linear or square root output
- Accuracy: 0.075% of span
- Long Term Stability: ±0.2% URL/60 months
- Operating Temperature: -20 to 70°C
- Storage Temperature: -40 to 85°C
- Media Temperature: -40 to 120°C
- Environmental Rating: IP67
- Housing Material: 316 Stainless Steel
- Process Connection: 1/4" NPT F / 316 SS
- Dimensions: Approx. 3kg weight, compact design
- Vibration Resistance: 20g (IEC standard)
- Sensor Fill Fluid: Silicone Oil
- Sensor Seal: FKM O-ring
- Response Time: 200 ms
- Transmission Distance: Up to 1000 meters
Buy the Omega PX3005 – Reliable Differential Pressure Transmitter for Industrial Applications
Purchase the Omega PX3005 differential pressure transmitter online today to ensure precise pressure monitoring in hydraulic systems, process automation, and tank level applications. Featuring a rugged IP67 stainless-steel enclosure, configurable 4-20mA output, and a clear backlit LCD, this device offers high accuracy and long-term stability. Its design supports various media temperatures and vibration resistance, making it ideal for challenging industrial environments. Order now and enhance your system’s reliability with Omega’s top-tier pressure measurement solutions.
Buy Omega PX3005 differential pressure transmitter now and experience unmatched accuracy, durability, and versatile configuration for demanding industrial environments.
Frequently Asked Questions
Where can I buy OMEGA PX3005STBPIPE?
You can click on the BUY or RFQ button to purchase PX3005STBPIPE from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part PX3005STBPIPE?
You can download the PX3005STBPIPE datasheet or visit the OMEGA website for support.
Who is the manufacturer of PX3005STBPIPE?
OMEGA
