OMEGA ZWED Wireless Sensor System
The OMEGA ZW-ED wireless sensor system provides reliable, long-range monitoring of temperature, humidity, and barometric pressure for industrial environments. Operating on IEEE 802.15.4 at 2.4 GHz, it transmits data up to 1000 meters in clear conditions to a compatible receiver connected via Ethernet or internet. The device features rugged NEMA 4 (IP65) weatherproof housing, making it suitable for indoor and outdoor use. It supports multiple probes, has a built-in web server, alarms via email, and configurable encryption for security. Power options include alkaline batteries with a 7-year lifespan and a backup lithium battery.
OMEGA ZWED Wireless Sensor System Specifications:
- Wireless Communication: IEEE 802.15.4, DSSS, 2.4 GHz, 16 channels
- Range: Up to 1000 meters (3280 feet) without obstructions or interference
- Transmit Power: 9.5 dBm
- Receiver Sensitivity: -96 dBm
- Input Voltage: 5 to 36 Vdc, 24 Vac +10%
- Input Power: 0.8 W maximum
- Power Supply: 5 Vdc @ 0.6 A (optional), 100-240 Vdc, 50/60 Hz
- Battery: Two C-cell 1.5 V alkaline batteries (7-year estimate), CR2032 backup
- Operating Temperature: 0 to 40°C (32 to 104°F), Battery -20 to 60°C
- Environmental Conditions: -20 to 70°C, 90% RH non-condensing
- Enclosure: Polycarbonate, NEMA 4 (IP65)
- Enclosure Dimensions: 135.9L x 82W x 39mmD (5.35 x 3.23 x 1.56 inches)
Buy the OMEGA ZW-ED – Reliable Wireless Transmitter for Industrial Applications
Purchase the OMEGA ZW-ED wireless sensor system today to ensure reliable monitoring of temperature, humidity, and pressure in industrial settings. Easily connect to Ethernet or the internet using the included receiver, which supports web-based data access, alarms by email, and encryption for security. Its rugged NEMA 4 enclosure and long-range transmission capability make it perfect for indoor or outdoor use. With a quick setup, powerful features, and a 7-year battery life, this sensor ensures continuous, accurate environmental monitoring for your applications.
Get OMEGA ZW-ED today—built for precision and long-lasting durability in demanding industrial environments.
Frequently Asked Questions
Where can I buy OMEGA ZWED?
You can click on the BUY or RFQ button to purchase ZWED from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part ZWED?
You can download the ZWED datasheet or visit the OMEGA website for support.
Who is the manufacturer of ZWED?
OMEGA
