ONSEMI MC78L09ABPRAG Voltage Regulator
The MC78L09ABPRAG is a positive voltage regulator that delivers a regulated 9.0V output with a maximum current of 100 mA. Designed for low-cost applications, it features internal short circuit current limiting and thermal overload protection, ensuring rugged performance without external components. Suitable for various electronic circuits requiring stable voltage regulation, the device operates within a temperature range of 40°C to +125°C. It comes in a TO-92 package with tape and reel packaging available for easy integration into manufacturing processes.
ONSEMI MC78L09ABPRAG Voltage Regulator Specifications:
- Output Voltage: 9.0V
- Maximum Output Current: 100mA
- Operating Temperature Range: 40°C to +125°C
- Package Type: TO-92
- Input Voltage Range: Up to 23V
- Line Regulation: typically 12-175mV at 40mA load
- Load Regulation: typically 8-90mV at 40mA load
- Dropout Voltage: approximately 17V input for full regulation
- Thermal Overload Protection: Yes
- Internal Short Circuit Current Limiting: Yes
- Operating Voltage Range: 5V to 23V
- Power Dissipation: up to 650mW depending on PCB cooling
- Features: Pb-Free, AEC-Q100 Qualified, PPAP Capable
Buy the ON Semiconductor Series MC78L09 Voltage Regulator: MC78L09ABPRAG
Enhance your electronic projects with the ON Semiconductor Series MC78L09 voltage regulator, providing a stable 9V output at up to 100mA. Designed for industrial, automotive, and consumer electronics, it features internal current limiting and thermal shutdown for rugged performance. Easy to implement with no external components required, the device operates reliably within -40°C to +125°C temperatures. Its compact TO-92 package simplifies mounting, ensuring dependable operation in space-constrained applications. Purchase online today for high-quality power regulation you can trust.
Order your ON Semiconductor Series MC78L09 voltage regulator today and ensure your projects benefit from reliable, stable power supply performance in all conditions.
Frequently Asked Questions
Where can I buy ONSEMI MC78L09ABPRAG?
You can click on the BUY or RFQ button to purchase MC78L09ABPRAG from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part MC78L09ABPRAG?
You can download the MC78L09ABPRAG datasheet or visit the ONSEMI website for support.
Who is the manufacturer of MC78L09ABPRAG?
ONSEMI
