ONSEMI MC79L12ABDG Negative Voltage Regulator
The MC79L12ABDG is an affordable, easy-to-use negative voltage regulator providing a stable -12V output. Designed for applications up to 100mA, it features thermal shutdown, current limiting, and internal short-circuit protection, ensuring rugged performance. Ideal for on-card regulation and other modest current requirements, this device eliminates the need for external components in most cases, simplifying circuit design. Its robust features make it suitable for various industrial, automotive, and electronic systems where reliable negative voltage regulation is critical, offering a cost-effective alternative to resistor or Zener diode solutions.
ONSEMI MC79L12ABDG Negative Voltage Regulator Specifications:
- Output Voltage: -12V
- Maximum Current: 100mA
- Thermal Shutdown: Yes
- Internal Short Circuit Protection: Yes
- Package Options: SOIC-8, TO-92
- Storage Temperature Range: -65°C to +150°C
- Junction Temperature Max: +150°C
- Voltage Supply Range: -16V to -27V
- Thermal Resistance Junction-to-Ambient: SOIC-8 - 180°C/W, TO-92 - 83°C/W
- Power Dissipation: Internally limited
- ESD Protection: Human Body Model 2000V, Machine Model 200V
- RoHS Compliant: Yes
Buy the ON Semiconductor Series MC79L12 Negative Voltage Regulator: MC79L12ABDG
Purchase the ON Semiconductor MC79L12ABDG negative voltage regulator online today and ensure stable -12V output with up to 100mA current capacity. This rugged device includes thermal shutdown and internal short-circuit protection, providing high reliability in industrial, automotive, and electronic applications. Designed for ease of use, it requires no external components in most cases, simplifying your circuit design and boosting efficiency. Secure your supply chain and improve your system's robustness by choosing this cost-effective and high-performance regulator for your next project.
Buy ON Semiconductor MC79L12ABDG now and experience unmatched reliability and performance in negative voltage regulation applications.
Frequently Asked Questions
Where can I buy ONSEMI MC79L12ABDG?
You can click on the BUY or RFQ button to purchase MC79L12ABDG from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part MC79L12ABDG?
You can download the MC79L12ABDG datasheet or visit the ONSEMI website for support.
Who is the manufacturer of MC79L12ABDG?
ONSEMI
