ONSEMI NL27WZ14DTT1G Dual Schmitt-Trigger Inverter
The NL27WZ14 is a high-performance dual inverter with Schmitt-Trigger inputs, operating from 1.65 to 5.5 V. It features hysteresis and noise margin enhancements, transforming slow-changing inputs into sharp, jitter-free outputs. Suitable for line receiver applications, it is designed for low power consumption with near-zero static current and over-voltage tolerant inputs/outputs. Its robust noise immunity, high drive capability, and compatibility with LVTTL and LVCMOS logic make it ideal for industrial and electronic device applications. Compliant with RoHS and AEC-Q100 standards, it is perfect for reliable signal processing and line receiving in various systems.
ONSEMI NL27WZ14DTT1G Dual Schmitt-Trigger Inverter Specifications:
- Operation Voltage: 1.65 V to 5.5 V
- Over Voltage Tolerant Inputs and Outputs
- Input Threshold Voltage (Vr+): 1.0 to 2.2 V
- Input Threshold Voltage (Vr-): 0.4 to 1.2 V
- Input Hysteresis: 0.25 to 0.75 V
- Output Voltage (HIGH): 1.29 to 1.52 V at Vcc=3 V
- Output Voltage (LOW): 0.08 to 0.24 V at Vcc=3 V
- Maximum DC Supply Voltage: 0 to 7.0 V
- DC Supply Current: 10 μA (typical at Vcc=5V)
- Power Dissipation in Still Air: 200 mW
- Maximum Power Dissipation: 200 mW
- Pin Configuration: SC-88/TSOP-6, SOT-363, 6-Pin Package
- Operating Temperature Range: -55°C to +125°C
- ESD Withstand Voltage: >2000 V (Human Body Model)
- Junction Temperature: Up to +150°C
- Chip Complexity: FET = 72
- RoHS Compliant, Pb-Free
Buy the ON Semiconductor NL27WZ14 – Reliable Schmitt-Trigger Inverter for Industrial Applications
Purchase the NL27WZ14 today through our online store—designed for reliable signal processing in industrial and electronic systems. This dual inverter features Schmitt-Trigger inputs with hysteresis, providing sharp output transitions and excellent noise immunity. Operating from 1.65V to 5.5V, it offers high drive capability of 24 mA and over-voltage tolerant inputs/outputs, making it suitable for line receivers and signal conversion. Its RoHS compliance and AEC-Q100 qualification ensure robust performance for demanding applications. Experience seamless integration, low power usage, and high quality—order now for fast delivery and technical support.
Get ON Semiconductor NL27WZ14 today—built for precision and long-lasting durability with high noise immunity and low power consumption in industrial electronics.
Frequently Asked Questions
Where can I buy ONSEMI NL27WZ14DTT1G?
You can click on the BUY or RFQ button to purchase NL27WZ14DTT1G from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part NL27WZ14DTT1G?
You can download the NL27WZ14DTT1G datasheet or visit the ONSEMI website for support.
Who is the manufacturer of NL27WZ14DTT1G?
ONSEMI
