Ohmite EY102KE Ceramic Power Resistor
The EY Series ceramic composition resistors are designed for high energy and peak power applications, offering higher reliability against disconnections compared to wirewound and film resistors. Suitable for automatic machine insertion, these lead-free devices meet EU RoHS requirements and feature a resistance range of 100Ω to 390KΩ with a tolerance of ±10%. They operate reliably within -40°C to +110°C, can withstand single impulses up to 25kV, and have a maximum working voltage of 550V. These resistors are ideal for high peak power circuits, with robust construction for industrial and electronic applications.
Ohmite EY102KE Ceramic Power Resistor Specifications:
- Resistance Range: 100Ω to 390KΩ
- Tolerance: ±10%
- Power Max.: 25W at 25°C
- Maximum Working Voltage: 550V
- Impulse Voltage: 25kV
- Operating Temperature Range: -40°C to +110°C
- Resistance Measurement Voltage: 0.3V to 3.0V at 25°C
- Resistance to Solvent: IPA or Xylene, no abnormal appearance after testing
- Resistance to Moisture: 40°C+2°C, 90-95% RH, 1000h cycles
- Physical Dimensions: Max diameter 3mm, length approx. 4.33 inches (110mm), in tape & reel packaging
- Construction: Ceramic composition with lead-free terminations, RoHS compliant
- TCR: <1002: -900±300ppm, 21000: -1200±300ppm
- Material: Ceramic, RoHS compliant
Buy the Ohmite Series EY Ceramic Power Resistor: EY102KE
Order the Ohmite EY102KE ceramic power resistor online today and experience dependable high energy performance. Designed for industrial and electronic applications, these resistors feature a resistance range of 100Ω to 390KΩ with ±10% tolerance, capable of handling 25W power at 25°C, and withstand impulse voltages up to 25kV. They're RoHS compliant, lead-free, and operate reliably between -40°C and +110°C. Perfect for high peak power circuits, they offer robust construction, ensuring long-lasting durability and consistent performance in demanding environments.
Get Ohmite EY102KE today—built for high energy and peak power reliability in industrial applications.
Frequently Asked Questions
Where can I buy Ohmite EY102KE?
You can click on the BUY or RFQ button to purchase EY102KE from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part EY102KE?
You can download the EY102KE datasheet or visit the Ohmite website for support.
Who is the manufacturer of EY102KE?
Ohmite
