Ohmite EY271KE ceramic power resistor
The EY Series ceramic composition resistors are high-energy, high peak power resistors suitable for automatic machine insertion and demanding industrial applications. They feature a lead-free termination compliant with EU RoHS requirements and offer higher reliability against disconnection compared to wirewound and film resistors. Rated for up to 25W with resistance ranges from 100Ω to 390KΩ and tolerances of ±10%. These resistors excel in high-voltage environments, withstand voltage surges up to 550V, and operate reliably within -40°C to +110°C, making them ideal for high energy pulse and power applications.
Ohmite EY271KE ceramic power resistor Specifications:
- Power Rating: 25W at 25°C
- Resistance Range: 100Ω to 390KΩ
- Tolerance: ±10%
- Max. Working Voltage: 550V
- Impulse Voltage: 25kV
- Temperature Range: -40°C to +110°C
- Resistance Measurement Voltage: 0.3V to 3.0V
- TCR: ±300 ppm over -40°C to +125°C
- Temperature Coefficient: <1002: -900+/- 300ppm, 21000: -1200+/-300ppm
- Moisture Resistance: 1000 hours at 40°C, 90%-95% RH
- Load Life: 1000 hours at 40°C, 1.5h ON/OFF cycles
- Solvent Resistance: IPA or Xylene dipping test
- Dimensions: Max. diameter 3mm, length approximately 0.039 in (1.0 mm)
- RoHS Compliant
- Ceramic Composition
Buy the Ohmite EY271KE – Reliable Ceramic Power Resistor for Industrial Applications
Discover the high-performance ceramic power resistor designed for demanding industrial environments. The EY271KE series offers reliable high energy pulse handling, resistance from 100Ω to 390KΩ, and operates safely in temperatures from -40°C to +110°C. With lead-free, RoHS-compliant terminations, these resistors are ideal for automatic insertion in power conversion, high voltage, and peak power applications. Trusted for durability, they withstand surges up to 550V and provide consistent performance over long operational periods, ensuring safe and efficient circuit protection and energy management.
Order your Ohmite Series EY271KE ceramic power resistor today and ensure your industrial applications have the high energy dissipation and high voltage reliability they demand.
Frequently Asked Questions
Where can I buy Ohmite EY271KE?
You can click on the BUY or RFQ button to purchase EY271KE from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part EY271KE?
You can download the EY271KE datasheet or visit the Ohmite website for support.
Who is the manufacturer of EY271KE?
Ohmite
