Ohmite FC4L110R003FER Current Sense Resistor
The FC4L Series features four-terminal current sense resistors with metal foil construction, designed for high stability and precision in industrial applications. These resistors support automatic insertion, offer industry-standard sizes, and are suitable for high heat resistant and low heat electromotive uses. Available in 2 watt and 5 watt packages, they incorporate Ni-Cu-Mn resistive elements, providing excellent temperature coefficient of resistance and durability. Ideal for precise current measurement, these resistors feature stable resistance values across a wide temperature range, making them suitable for sophisticated electrical and electronic systems.
Ohmite FC4L110R003FER Current Sense Resistor Specifications:
- Power Ratings: 2W (FC4L64), 5W (FC4L110)
- Resistance Range: 1mΩ to 50mΩ
- Temperature Coefficient of Resistance: ±50 to ±100 ppm/°C
- Operating Temperature Range: -55°C to +155°C (FC4L110: -40°C to +125°C)
- Max Temperature for Rated Power: 70°C
- Resistance Tolerance: ±0.5% to ±2%
- Maximum overload: Rated power x 1.5 for 5 seconds
- In-rush current: Up to 100A depending on series
- Soldering Temp: 260°C for 10 seconds
- Storage Humidity: 90-95% RH at 60°C
- Mechanical Dimensions: Length varies with series, typical 0.063/1.60 mm for FC4L16 and scaled for larger ones
- Construction: Metal foil with Ni-Cu-Mn resistive element, epoxy coating for protection
- Reliability: UL Listed and RoHS Compliant
- Application: Precision current sensing, load measurement, industrial automation
Buy the Ohmite FC4L110 R– Reliable Precision Resistor for Industrial Applications
Purchase the high-accuracy Ohmite FC4L110 current sense resistor online today and ensure reliable current measurement for your industrial projects. Designed with durable metal foil construction, these resistors deliver stable resistance across a wide temperature range, supporting high heat and low electromotive conditions. Ideal for circuit protection, load detection, and precise electrical measurements, they feature industry-standard sizes and robust specifications. Enhance your systems' accuracy and performance by choosing this dependable resistor for your precision electronic applications. Order now for quick delivery and excellent performance.
Get Ohmite FC4L110 today—built for precision and long-lasting durability in critical industrial applications.
Frequently Asked Questions
Where can I buy Ohmite FC4L110R003FER?
You can click on the BUY or RFQ button to purchase FC4L110R003FER from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part FC4L110R003FER?
You can download the FC4L110R003FER datasheet or visit the Ohmite website for support.
Who is the manufacturer of FC4L110R003FER?
Ohmite
