Ohmite FC4L76R020FER Four-terminal current sensing resistor
The FC4L Series consists of four-terminal current sensing resistors with metal foil construction, designed for stability and accuracy in industrial applications. These resistors feature industry-standard sizes, high heat resistance, and low electromotive force, making them suitable for automatic insertion and demanding environments. Available in 2W and 5W packages, they incorporate Ni-Cu-Mn resistive elements with a built-in four-terminal Kelvin design for precise current management and measurement. Their reliable performance and robust construction ensure consistent operation across various temperatures and conditions.
Ohmite FC4L76R020FER Four-terminal current sensing resistor Specifications:
- Power Series Rating: 2W, 5W
- Resistance Range: 0.25mΩ to 100mΩ (varies by series)
- Tolerance: ±0.5%, ±1%, ±2%, ±3%
- Temperature Coefficient of Resistance: ±41% to ±45% (ppm/°C)
- Maximum Operating Temperature: -40°C to +155°C
- Rated Voltage: (Rated Power x Resistance Value)
- Overload Voltage: 1.5 times rated voltage for 5 seconds
- In-rush Current: Up to 95A (varies by size)
- Dimensions: Industry standard sizes, detailed specifications per series
- Construction: Metal foil with Ni-Cu-Mn resistive element, four-terminal Kelvin design
- Approvals: RoHS compliant, suitable for automatic insertion
- Packaging: Reels with specific tape and reel dimensions for automated PCB assembly
Buy the Ohmite FC4L – Reliable Current Sense Resistors for Industrial Applications
Purchase the Ohmite FC4L Series four-terminal current sense resistors online today and benefit from high stability, excellent heat resistance, and precise current measurement capabilities. Designed for demanding industrial environments, these resistors come in multiple wattages and resistance ranges, providing flexibility and reliability for your electrical and electronic applications. Easy to integrate into automated manufacturing processes due to industry-standard sizes and RoHS compliance. Get your authentic FC4L Series resistor now and enhance your current sensing solutions with proven quality.
Order your Ohmite FC4L Series current sense resistor today and ensure precise, stable current measurement for your industrial projects.
Frequently Asked Questions
Where can I buy Ohmite FC4L76R020FER?
You can click on the BUY or RFQ button to purchase FC4L76R020FER from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part FC4L76R020FER?
You can download the FC4L76R020FER datasheet or visit the Ohmite website for support.
Who is the manufacturer of FC4L76R020FER?
Ohmite
