Ohmite FC4TR010DER Low Resistance Chip
The FC4T chip features a four-terminal Kelvin configuration, allowing precise current measurement by applying current through two terminals and sensing voltage across the other two. Its design minimizes the effects of terminal resistance and temperature variations. Utilizing Ohmite's proprietary Metal Foil technology, it offers an excellent Temperature Coefficient of Resistance (TCR), even for very low resistance values down to 50ppm. Rated at 0.5W, it operates within -55°C to +155°C, with resistance values ranging from 0.005Ω to 0.100Ω and standard tolerances of 0.5% and 1%. Its epoxy resin coating and copper/ nickel/ tin terminals enhance durability, making it suitable for high-precision, low-resistance applications.
Ohmite FC4TR010DER Low Resistance Chip Specifications:
- Power Rating: 0.5W at 70°C
- Resistance Range: 0.005Ω to 0.100Ω
- Resistance Tolerance: 0.5% and 1%
- Temperature Coefficient of Resistance: 50ppm/°C
- Operating Temperature Range: -55°C to +155°C
- Coating Material: Epoxy resin
- Terminals: Cu/Ni/Sn
- Max. Current: 27.5A (at rated power)
- Construction: Epoxy resin, copper alloy resistor, alumina substrate
- Max. Resistance of Electrodes: <5mΩ
- Flammability: UL 94V-0
- Contact Materials: Copper with Ni/Sn plating
- Certifications: Compliant with relevant standards
Buy the Ohmite Series FC4T Metal Foil Low Value Chip: FC4TR010DER
Purchase the Ohmite FC4TR010DER low resistance chip online today to ensure your high-precision electrical measurements. Featuring a four-terminal Kelvin configuration, it minimizes terminal resistance effects for accurate current sensing. Constructed with proprietary Metal Foil technology, it offers an excellent Temperature Coefficient of Resistance of 50ppm and operates from -55°C to +155°C. Its 0.5W power rating and resistance range of 0.005Ω to 0.100Ω make it ideal for precision measurement, testing, and control applications, providing reliable performance for demanding environments.
Buy Ohmite FC4TR010DER now and experience unmatched reliability and performance with high precision low resistance measurement technology.
Frequently Asked Questions
Where can I buy Ohmite FC4TR010DER?
You can click on the BUY or RFQ button to purchase FC4TR010DER from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part FC4TR010DER?
You can download the FC4TR010DER datasheet or visit the Ohmite website for support.
Who is the manufacturer of FC4TR010DER?
Ohmite
