Ohmite FCSL110R005DER Metal Foil Current Sense Resistor
Ohmite's FCSL series metal foil current sense resistors provide exceptional stability and performance for demanding current sensing applications. Utilizing proven metal foil technology, these resistors exhibit very low and stable Temperature Coefficient of Resistance (TCR) values and are available in a wide range of low ohmic values. With power ratings up to 10 Watts, the FCSL series is ideal for applications requiring precise current measurement and control. They are designed for automatic insertion and offer high heat resistance, ensuring reliable operation in challenging environments.
Ohmite FCSL110R005DER Metal Foil Current Sense Resistor Specifications:
- Power Resistance: 2.0W, 3.0W, 4.0W, 5.0W, 10.0W
- TCR: ±5% ±150, ±2% ±100, ±1% ±50, ±0.5% ±50
- Weight: 0.036g, 0.050g, 0.071g, 0.096g, 0.316g
- Rating Range (mΩ): 3m ~ 100m, 10m ~ 50m
- Series: FCSL64, FCSL76, FCSL90, FCSL110, FCSL150
- Tol.(ppm/°C): ±5% ±150, ±2% ±100, ±1% ±50
- In-rush Current (1mΩ~10mΩ): 125A, 150A, 180A, 210A, 240A
- In-rush Current (12mΩ~100mΩ): 70A, 80A, 100A, 120A, 140A
- Derating: 60, 80
- Recommended Reflow Temperature Profile: Preheating: 130° ~ 180° 60s ~ 90s, Heating: Over 220° 30s ~ 90s
- Operating Temperature Range: -55°C ~ +155°C
Buy the FCSL110R005DER OHMITE Metal Foil Current Sense Resistor | myMectronic
Purchase the OHMITE FCSL110R005DER Metal Foil Current Sense Resistor securely and conveniently online.
