Ohmite FCSL76R005DER Metal Foil Current Sense Resistor
The OHMITE FCSL series represents a significant advancement in current sense resistor technology. Utilizing proven metal foil construction, these resistors deliver exceptional stability and accuracy, characterized by very low and stable Temperature Coefficient of Resistance (TCR). Available in a wide selection of low ohmic values, the FCSL series is designed for automatic insertion and offers high heat resistance. With power ratings up to 10 Watts, the FCSL76R005DER is an ideal choice for a broad range of current sensing applications across various industrial sectors, including power supplies, motor drives, and battery management systems. Its robust design and reliable performance ensure accurate current measurement and system protection.
Ohmite FCSL76R005DER Metal Foil Current Sense Resistor Specifications:
- Power Resistance: 1mΩ - 100mΩ
- TCR: ±50 ppm/°C to ±150 ppm/°C
- Weight: 0.036g - 0.316g
- Series: FCSL64, FCSL76, FCSL90, FCSL110, FCSL150
- Rating Range (mΩ): 3m ~ 100m
- Tolerance: ±0.5% to ±5%
- Rated Power: 2W - 10W
- Operating Temperature Range: -55°C ~ +155°C
- Derating: See datasheet
- Recommended Reflow Temperature Profile: Preheating: 130° ~ 180° 60s ~ 90s, Heating: Over 220° 30s ~ 90s
- In-rush Current: See table
- Moisture Resistance: 60°C ±2°C, 90~95% RH, Rated voltage 1.5h ON, 0.5h OFF 1000h
Buy the FCSL76R005DER OHMITE Metal Foil Current Sense Resistor | myMectronic
Purchase the OHMITE FCSL76R005DER with confidence and security through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy Ohmite FCSL76R005DER?
You can click on the BUY or RFQ button to purchase FCSL76R005DER from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part FCSL76R005DER?
You can download the FCSL76R005DER datasheet or visit the Ohmite website for support.
Who is the manufacturer of FCSL76R005DER?
Ohmite
