Ohmite FCSL76R025DER Metal Foil Current Sense Resistor
The OHMITE FCSL series represents a significant advancement in current sense resistor technology. Utilizing proven metal foil construction, these resistors deliver exceptional stability and accuracy. The FCSL76R025DER specifically offers a combination of very low and stable Temperature Coefficient of Resistance (TCR) values, available in a wide selection of low ohmic values. With power ratings up to 10 Watts, the FCSL series is an ideal choice for current sensing applications in power supplies, motor drives, and other industrial equipment. Its design facilitates automatic insertion, and it meets industry standard sizes for ease of integration.
Ohmite FCSL76R025DER Metal Foil Current Sense Resistor Specifications:
- Power Resistance: 1mΩ, 2mΩ, 3mΩ ~ 100mΩ
- TCR: ±5% ±150, ±2% ±100, ±1% ±50, ±0.5% ±50
- Weight: 0.036g, 0.050g, 0.071g, 0.096g, 0.316g
- Series: FCSL64, FCSL76, FCSL90, FCSL110, FCSL150
- Rating Range (mΩ): 3m ~ 100m
- Tol.(ppm/°C): ±5% ±150, ±2% ±100, ±1% ±50, ±0.5% ±50
- Rated Power: 2.0W, 3.0W, 4.0W, 5.0W, 10.0W
- Derating: 60, 80
- Recommended Reflow Temperature Profile: Preheating: 130° ~ 180° 60s ~ 90s, Heating: Over 220° 30s ~ 90s
- In-rush Current: √(in-rush power/resistance value)
- Operating Temperature Range: -55°C ~ +155°C
