Ohmite FCSL76R050DER Metal Foil Current Sense Resistor
The OHMITE FCSL series metal foil current sense resistors offer exceptional stability and precision for demanding current sensing applications. Utilizing proven metal foil technology, these resistors provide very low and stable Temperature Coefficient of Resistance (TCR) values, ensuring accurate measurements across a wide range of operating conditions. The FCSL series is designed for automatic insertion, features industry-standard sizes, and offers high heat resistance, making them ideal for use in power supplies, motor drives, and other industrial applications. Available in a variety of ohmic values and power ratings, the FCSL series provides a reliable and robust solution for current sensing needs.
Ohmite FCSL76R050DER Metal Foil Current Sense Resistor Specifications:
- Power Resistance: 1mΩ, 2mΩ, 3mΩ, 10mΩ, 100mΩ
- TCR: ±5% ±150ppm/°C, ±2% ±100ppm/°C, ±1% ±50ppm/°C, ±0.5% ±50ppm/°C
- Weight: 0.036g, 0.050g, 0.071g, 0.096g, 0.316g
- Series: FCSL64, FCSL76, FCSL90, FCSL110, FCSL150
- Rating Range (mΩ): 3m ~ 100mΩ
- Tolerance: ±1%, ±0.5%
- Power Rating: 2.0W, 3.0W, 4.0W, 5.0W, 10.0W
- Operating Temperature Range: -55°C ~ +155°C
- Derating: See datasheet
- Recommended Reflow Temperature Profile: Preheating: 130° ~ 180° 60s ~ 90s, Heating: Over 220° 30s ~ 90s
- In-rush Current: See table
- Moisture Resistance: 60°C ±2°C, 90~95% RH, Rated voltage 1.5h ON, 0.5h OFF 1000h
Buy the FCSL76R050DER OHMITE Metal Foil Current Sense Resistor | myMectronic
Purchase the OHMITE FCSL76R050DER Metal Foil Current Sense Resistor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Ohmite FCSL76R050DER?
You can click on the BUY or RFQ button to purchase FCSL76R050DER from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part FCSL76R050DER?
You can download the FCSL76R050DER datasheet or visit the Ohmite website for support.
Who is the manufacturer of FCSL76R050DER?
Ohmite
