Ohmite HS10015RF Aluminium Housed Resistors
High-power aluminium housed resistors designed for industrial applications, compliant with MIL 18546 and IEC 115 standards. These resistors are optimized for direct heatsink mounting using thermal compound, providing efficient heat dissipation with a maximum surface temperature of 200°C. Available with various ohmic values from R005 to 100K, they feature high pulse capability, low inductance options, and custom designs. Suitable for power dissipation in high ambient temperatures, they are RoHS compliant, with tolerance options from ±1% to ±10%, ensuring reliable performance in demanding environments.
Ohmite HS10015RF Aluminium Housed Resistors Specifications:
- Power Ratings: From 4W to 300W depending on model and heat sink
- Resistance Range: R005 to 100K ohms
- Tolerance: Standard +5% (J), +10% (K); options include +1% (F), +2% (G), +3% (H)
- Temperature Coefficient: Typically < 1K 100ppm, > 1K 25ppm
- Insulation Resistance (Dry): ≥10,000 MΩ
- Maximum Surface Temperature: 200°C with appropriate heat sinking
- Heat Dissipation: Linearly derates at high ambient temperatures, requiring thermal management
- Voltage Proof AC: Up to 1400V depending on model
- Voltage Proof DC: Up to 1000V depending on model
- Physical Dimensions: Range from 16.5mm to 72.5mm in size, detailed dimensional data available for each model
- Materials: Aluminium housing, wound wire elements, RoHS compliant
- Special Features: Low inductance options, high pulse capability, custom designs accepted
Buy the Arcol HS100 – Reliable Aluminium Housed Resistors for Industrial Applications
Purchase the Arcol HS100 aluminium housed resistor online today for reliable high-power performance, efficient heat management, and customizable options. Perfect for industrial applications needing high pulse capability and stable operation, these resistors are RoHS compliant and designed for direct heatsink mounting with thermal compound. With various resistance and tolerance options, they ensure optimal performance even at high ambient temperatures. Act now to enhance your electronic systems with these durable, high-quality resistors, available for quick and secure online ordering for seamless integration into your projects.
Order your Arcol Series HS100 aluminium housed resistor today and ensure dependable performance in your high-power electronic projects.
Frequently Asked Questions
Where can I buy Ohmite HS10015RF?
You can click on the BUY or RFQ button to purchase HS10015RF from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part HS10015RF?
You can download the HS10015RF datasheet or visit the Ohmite website for support.
Who is the manufacturer of HS10015RF?
Ohmite
