Ohmite HS101R5J Aluminium Housed Resistor
The HS Aluminium Housed Resistors are high-power, heat sink-mounted components designed for reliable operation in various electrical applications. Manufactured in compliance with MIL 18546 and IEC 115 standards, these resistors feature wound construction for high pulse capability and excellent thermal performance. Available in ohmic values from R005 to 100K, they are RoHS compliant and tailored for direct heatsink mounting with thermal compound. Suitable for high ambient temperatures, they offer low inductance options (NHS). Custom designs are possible to meet specific performance requirements, making them ideal for industrial, aerospace, and electronic applications needing robust resistors with efficient heat dissipation.
Ohmite HS101R5J Aluminium Housed Resistor Specifications:
- Power Dissipation: 10 W to 300 W depending on model and heat sink mounted
- Resistance Range: R005 to 100K ohms
- Tolerance: ±5% (J), ±10% (K); also available ±1% (F), ±2% (G), ±3% (H)
- Temperature Coefficient: < 1K 100ppm, > 1K 25ppm
- Insulation Resistance: Minimum 10,000 MΩ (dry)
- Surface Temperature Rise: Controlled by heat sink, max 200°C hotspot
- Voltage Ratings: Divide standard max working voltage by 1.414 for NHS types
- RoHS Compliant: Yes
- Construction: Aluminium housed, wound for pulse capability, optionally low inductance NHS
- Dimensions: Varied by size, detailed in datasheet
Buy the Buy ARCOL Aluminium Housed Resistors Part Number HS101R5J Online
Purchase the ARCOL HS101R5J aluminium housed resistor online today to ensure your electronic and industrial projects benefit from high power handling, efficient heat dissipation, and reliable performance. Designed for direct heatsink mounting with thermal compound, these resistors meet strict standards and offer customizable resistance values from R005 to 100K. Ideal for high ambient temperature environments, they are RoHS compliant and feature low inductance options. Secure your supply online for fast delivery and professional support to enhance your electrical systems.
Buy ARCOL HS101R5J aluminium housed resistor now and experience unmatched reliability, high pulse power, and efficient heat dissipation for your industrial needs.
Frequently Asked Questions
Where can I buy Ohmite HS101R5J?
You can click on the BUY or RFQ button to purchase HS101R5J from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part HS101R5J?
You can download the HS101R5J datasheet or visit the Ohmite website for support.
Who is the manufacturer of HS101R5J?
Ohmite
