Ohmite HS2533RJ Aluminium Housed Resistor
HS Aluminium Housed Resistors are high-performance, high-power components designed for direct heatsink mounting for optimal thermal management. Manufactured according to MIL 18546 and IEC 115 standards, these resistors are wound to maximize pulse capability with ohmic values from R005 to 100K. They feature low inductance options, custom designs, RoHS compliance, and tolerance options from ±1% to ±10%. Suitable for applications requiring reliable power dissipation up to 300 Watts, these resistors are mounted on heat sinks with thermal compound for maximum heat transfer, ensuring safe operation below 200°C surface temperature.
Ohmite HS2533RJ Aluminium Housed Resistor Specifications:
- Power Dissipation: Up to 300W, derates linearly to zero at 200°C surface temperature
- Ohmic Values: R005 to 100K depending on size and wattage
- Tolerance: ±1% (F), ±2% (G), ±5% (J), ±10% (K)
- Temperature Coefficient: <1K 100ppm, >1K 25ppm
- Insulation Resistance (Dry): ≥10,000 MΩ
- Surface Temperature Rise: Allows heat dissipation with heat sink compound to maintain below 200°C
- Voltage Ratings: Up to 6363V Peak RMS, rated limit specified per series
- Dimensions: Range from approx. 16.5 mm to 72.5 mm in size depending on model, with detailed measurements for each
- Construction: aluminium housing suitable for direct heatsink mounting, RoHS compliant, wound for pulse capability
Buy the Arcol Series HS Resistors: High Power Aluminium Housed Resistors R005-100K
Order Arcol HS aluminium housed resistors online today to benefit from high power handling, customizable tolerance options, low inductance models, and RoHS compliance. These resistors are designed for direct heatsink mounting with optimal thermal performance, suitable for high pulse and continuous power applications up to 300 Watts. With precise temperature management and robust insulation resistance, they ensure safe operation below 200°C. Easily configured with detailed size options, these resistors provide reliable performance for industrial and high-power electronic systems.
Buy Arcol HS Series aluminium housed resistors now and experience unmatched reliability and high pulse power capability for demanding applications.
Frequently Asked Questions
Where can I buy Ohmite HS2533RJ?
You can click on the BUY or RFQ button to purchase HS2533RJ from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part HS2533RJ?
You can download the HS2533RJ datasheet or visit the Ohmite website for support.
Who is the manufacturer of HS2533RJ?
Ohmite
