Ohmite HS75220RJ High Power Aluminium Resistor
The HS75220RJ is an aluminium housed resistor designed for high power applications with direct heatsink mounting and thermal compound. It features high pulse capabilities, RoHS compliance, and adjustable tolerance levels. Suitable for demanding environments, it offers reliable performance across a wide ohmic range from R005 to 100K, with specifications tailored for high-temperature environments and efficient heat dissipation. Its robust construction ensures durability, making it ideal for industrial, power electronics, and high-temperature circuit applications requiring dependable resistance and heat management.
Ohmite HS75220RJ High Power Aluminium Resistor Specifications:
- Power Dissipation: Ranges from 0.5W to 300W depending on model and cooling method.
- Resistance Range: R005 to 100K ohms.
- Tolerance: Standard +5% (J), +10% (K), optional +1% (F), +2% (G), +3% (H).
- Temperature Coefficient: Typically < 1K 100ppm, > 1K 25ppm.
- Insulation Resistance (Dry): 10,000 MΩ minimum.
- Heat Dissipation: Derates linearly to zero at 200°C ambient temperature.
- Surface Temperature Rise: Maintained below 200°C for optimal performance.
- Dimensions: Vary per size, e.g., HS75: Ø24mm, HS150: Ø41.8mm, detailed dimensions include maximum A, B, C, D, E, F, G, H, J, K, L, M for each size.
- Mounting: Designed for direct heatsink mounting with thermal compound for maximum heat transfer.
- Construction: Aluminium housing for efficient heat dissipation, with optional low inductance (NHS) versions.
- Certifications: RoHS compliant, conforming to industry standards for safety and reliability.
Buy the Arcol Series HS Resistor: HS75220RJ
Purchase the Arcol HS75220RJ aluminium housed resistor online today for reliable high power resistance with excellent heat dissipation. Designed for industrial and power electronic applications, it supports direct heatsink mounting and offers precise resistance ratings from R005 to 100K. Its robust aluminium construction ensures durability under demanding conditions, while the optional low inductance features optimize performance in high pulse environments. Shop now to enhance your projects with trusted thermal management and industry-approved quality assured for lasting reliability.
Order your Arcol Series HS75220RJ high power resistor today and ensure your electronic systems operate with dependable heat management and precision.
Frequently Asked Questions
Where can I buy Ohmite HS75220RJ?
You can click on the BUY or RFQ button to purchase HS75220RJ from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part HS75220RJ?
You can download the HS75220RJ datasheet or visit the Ohmite website for support.
Who is the manufacturer of HS75220RJ?
Ohmite
