Ohmite KDV02FR560ET Metal Film Chip Resistor
KDV series metal film low-resistance chip resistors are designed for precise current sensing and high power applications. They offer low resistance, low TCR, and minimal inductance, ensuring excellent long-term stability. Suitable for use in consumer electronics, computers, telecom devices, measuring instruments, industrial equipment, power supplies, and battery management systems. Operate reliably within a temperature range of -55°C to +155°C.
Ohmite KDV02FR560ET Metal Film Chip Resistor Specifications:
- Series: KDV Series
- Sizes: 0201, 0402, 0603, 0805, 1206
- Power Ratings: 1/10W to 1/2W depending on size
- Resistance Range: 50mΩ to 1000mΩ
- Max. Operating Temperature: -55°C to +155°C
- TCR: +125 ppm/°C (typical)
- Overload Power: 6.25 times rated power for 5 seconds
- Insulation Resistance: 100V for 1 minute is >10 GΩ
- Solderability: 95% coverage, no damage after 245°C for 3-5 seconds
- Storage: Up to one year at 25°C and 60% humidity
- Reflow Soldering: Peak temperature 260°C, recommended 280°C for reflow process
- Operating Current: Ranges based on resistance and size, typically up to 4.47A
- Compliance: RoHS
- Environmental: Tested for temperature cycling, humidity, resistance to solvents, load life, and terminal strength
Buy the Ohmite Series KDV: Metal Film Low-Resistance Chip Resistor: KDV02FR560ET
Enhance your electronic assemblies with the reliable Metal Film Chip Resistor from the KDV Series. Designed for high-precision current sensing and power applications, this resistor offers excellent long-term stability, low resistance, and minimal inductance. Operating efficiently across temperatures from -55°C to +155°C, it is ideal for consumer electronics, telecom, industrial, and battery management systems. Available in various sizes with high overload capabilities, order online today and ensure your projects deliver consistent, dependable performance with top-quality resistors.
Order your Ohmite Series KDV02FR560ET today and enhance your high-precision current sensing projects with reliable, low-resistance resistors.
Frequently Asked Questions
Where can I buy Ohmite KDV02FR560ET?
You can click on the BUY or RFQ button to purchase KDV02FR560ET from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part KDV02FR560ET?
You can download the KDV02FR560ET datasheet or visit the Ohmite website for support.
Who is the manufacturer of KDV02FR560ET?
Ohmite
