Ohmite KDV08FR120ET Low-Resistance Chip Resistor
The KDV08FR120ET is a high-precision, low-resistance metal film chip resistor designed for accurate current sensing and power applications. It features excellent long-term stability, halogen and lead-free compliance, and is suitable for consumer electronics, industrial power supplies, and battery management systems. With a rated power of 0.25W, resistance range from 100mΩ to 1000mΩ, operating temperatures from -55°C to +155°C, and TCR of +50 ppm/°C, it meets rigorous safety and performance standards. Its compact size and thermal stability make it ideal for high-reliability electronic circuits.
Ohmite KDV08FR120ET Low-Resistance Chip Resistor Specifications:
- Size: 0805 (2.00+0.10mm x 1.25+0.10mm x 0.055+0.10mm)
- Power Rating: 0.25W at 70°C
- Resistance Range: 100mΩ to 1000mΩ
- Maximum Overload Current: 5.00A
- Maximum Overload Power: 0.25W
- Temperature Coefficient of Resistance (TCR): +50 ppm/°C
- Operating Temperature Range: -55°C to +155°C
- Material: Metal film
- Lead-Free and Halogen-Free: Yes
- Compliance: RoHS
- Storage: 25°C, 60% humidity, valid for 1 year from delivery
- Test Methods: Temp. Coefficient per JIS C 5201-1, clause 4.8; Resistance: <19 mΩ; Short Time Overload: 6.25× rated power for 5 seconds
- Solderability: 245°C for 3 sec, 95% coverage
- Humidity Resistance: 100V for 1 min, 10GΩ
- Load Life: 1000 hrs at rated power, ±1% resistance change
- Wave Soldering: Peak 260°C, profile in accordance with recommended reflow profiles
- Reel Quantity: 5K pcs per reel
Buy the Buy Ohmite KDV08FR120ET Part Number 120Ω Online
Discover the high-quality Ohmite low-resistance chip resistor KDV08FR120ET available online. Designed for precise current sensing, it offers excellent stability, thermal performance, and is halogen and lead-free compliant. Its small size and reliable performance make it suitable for consumer electronics, power supplies, and industrial systems. Easy to integrate with excellent long-term stability and compliance with RoHS standards. Order now and enhance your electronic circuit's accuracy and durability with this advanced resistor component.
Order your Ohmite SeriesKDV08FR120ET resistor today and ensure reliable high-precision current sensing for your electronic projects.
Frequently Asked Questions
Where can I buy Ohmite KDV08FR120ET?
You can click on the BUY or RFQ button to purchase KDV08FR120ET from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part KDV08FR120ET?
You can download the KDV08FR120ET datasheet or visit the Ohmite website for support.
Who is the manufacturer of KDV08FR120ET?
Ohmite
