Ohmite LVT12R0100FER Current Sense Resistor
The Ohmite LVT series comprises metal alloy strip resistors designed for precise current sensing applications. With resistance values ranging from 2mΩ to 20mΩ, these resistors feature excellent TCR ratings as low as 50ppm, and tight tolerances down to 1%. Available in various sizes including 0402, 0603, 0805, and 1206, they offer power ratings from 0.33W to 1.0W. The series is ideal for stable current measurement with high reliability at operating temperatures from -55°C to +155°C, incorporating epoxy resin coatings and lead terminals with matte tin finish.
Ohmite LVT12R0100FER Current Sense Resistor Specifications:
- Resistance Range: 0.002 - 0.020 ohms
- Power Ratings: 0.33W (0402, 0603), 0.5W (0805), 1.0W (1206)
- Temperature Coefficient: 50, 75, 100, 150 ppm/°C
- Resistance Tolerance: 1%, 2%, 3%
- Operating Temperature Range: -55°C to +155°C
- Rated Ambient Temperature: +70°C
- Coating Material: Epoxy resin
- Terminals: 100% matte tin
- Storage Conditions: Airtight storage for 2 years at 10-40°C, humidity <75%
- Construction: Cu-alloy resistor with flame-retardant epoxy coating
- Compliance: RoHS
Buy the Buy Ohmite Current Sense Resistor Part Number LVT12R0100FER Online
Order the Ohmite LVT12R0100FER current sense resistor online today to enhance your circuit's stability and accuracy. Featuring a resistance of 0.01 ohms, a power rating of 1 watt, and a low TCR of 50ppm, it provides precise current measurement across a wide temperature range from -55°C to +155°C. Its epoxy coating ensures durability, while matte tin terminals guarantee reliable connections. Ideal for high-performance electronic designs, this resistor ensures consistent operation under demanding conditions. Buy now and improve your project's reliability.
Buy Ohmite LVT12R0100FER low value current sense resistor now and experience unmatched reliability and precision in your electronic applications.
Frequently Asked Questions
Where can I buy Ohmite LVT12R0100FER?
You can click on the BUY or RFQ button to purchase LVT12R0100FER from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part LVT12R0100FER?
You can download the LVT12R0100FER datasheet or visit the Ohmite website for support.
Who is the manufacturer of LVT12R0100FER?
Ohmite
