Ohmite MOX3N131005FE High Voltage Precision Resistor
The OHMITE Maxi-Mox MOX-3N-131005FE resistor is a versatile and robust component ideal for demanding industrial applications. It offers high voltage and power handling capabilities, making it suitable for HV power supplies, power distribution, medical instrumentation, and avionics. Available with silicone or epoxy coating, and a range of tolerances, this resistor provides reliable performance in harsh environments. Its axial terminal design allows for easy integration into various circuit designs.
Ohmite MOX3N131005FE High Voltage Precision Resistor Specifications:
- Resistance Range: 750Ω to 1,000,000M
- Power Rating: 7.5W @70°C
- Voltage Rating: 30.0KV
- Available Tolerances: 1% to 20%
- Capacitance: 0.50 pf
- Core Material: Alumina
- Resistor Type: Thick Film
- Terminal Composition: 96% Sn, 3.5% Ag, 0.5% Cu
- Resistance Range (Value): 250Ω to 1 Teraohm
- Power Rating (Value): 2.0W to 12.5W
- Voltage Rating (Value): 10KV to 50KV
- Tolerance: 0.5% to 20%
- Operating Temperature: -55°C to +210°C
- Temperature Coefficient of Resistance: < 2PPM/Volt
- Humidity Test: ±0.25% (MIL-STD-202,Method 103B,Condition B)
- Dielectric Withstanding Voltage: ±0.25% (MIL-STD-202,Method 301,750V)
- Insulation Resistance: >10,000 M (MIL-STD-202,Method 302)
- A Max Dimension: 3.120” / 79.24
- B Max Dimension: 0.310” / 7.87
- Lead Diameter: 0.032” typ.
