Ohmite SM102031007FE High-Voltage Thick Film Resistor
The SM102031007FE is a 1 GΩ, 1-watt through-hole mounting thick film resistor featuring 0.032-inch standard radial leads and a low outgassing epoxy coating. The Slim-Mox resistor offers stable performance across a wide resistance range, with voltage ratings up to 25 kV. It provides high dielectric strength, low noise, and is non-inductive, making it suitable for high-stability circuit applications.
Ohmite SM102031007FE High-Voltage Thick Film Resistor Specifications:
- Resistance Range: 1GΩ
- Power Rating: 1W
- Voltage Rating: 25KV
- Resistance Tolerance: 5%
- Temperature Coefficient of Resistance: Tracking to 10ppm
- Resistance Ratio: 100:1 - 5000:1
- Thick film on Alumina
- Coating: Epoxy
- Terminals: Radial, 0.032 inch (0.813 mm)
- Temperature Range: -55°C to +110°C
- Resistance TCR tracking: 10ppm
- VCR tracking: 1ppm
- Operating Temperature: -55°C to +180°C
- Flammability: UL 94V-0
- Insulation Resistance: >10,000MΩ
- Dielectric Withstanding Voltage: 750V
- Humidity Resistance: 40.25%
- Shock, Vibration, Solderability, and other MIL-STD tested features are compliant.
Buy the Buy Ohmite Resistance Part Number SM102031007FE Online
Experience the reliability and precision of the Ohmite SM102031007FE resistor, offering a resistance of 1 GΩ with 1W power rating and 25kV voltage. Its thick film design on alumina ensures high stability, low noise, and non-inductive performance. Suitable for high-stability circuits in medical and power supply applications, it features radial terminals with a 0.032-inch diameter and a tough epoxy coating for durability. Perfect for precision engineers seeking robust, high-voltage resistor solutions available for purchase online.
Get Ohmite SM102031007FE today—built for precision and long-lasting durability in high-voltage applications.
Frequently Asked Questions
Where can I buy Ohmite SM102031007FE?
You can click on the BUY or RFQ button to purchase SM102031007FE from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part SM102031007FE?
You can download the SM102031007FE datasheet or visit the Ohmite website for support.
Who is the manufacturer of SM102031007FE?
Ohmite
