Ohmite TUM5J10KE High Power Ceramic Resistor
This ceramic metal oxide resistor is engineered for high-power applications, delivering reliable performance under demanding electrical loads. Its ceramic housing and inorganic construction ensure excellent flameproof and thermal stability, making it suitable for industrial environments. With a resistance range from 180 ohms to 33K ohms and wattage options up to 15W, it provides versatility for various circuit requirements. The resistor features a derating curve for temperature resilience, a dielectric withstand capacity of 1,000VAC, and is compliant with RoHS standards. Designed for stability and durability, it’s ideal for commercial and industrial high-current applications.
Ohmite TUM5J10KE High Power Ceramic Resistor Specifications:
- Housing: Ceramic
- Core: Fiberglass or metal oxide
- Filling: Cement-based
- Tolerance: 5%
- TCR: 0.01-202 +400ppm/°C
- Dielectric Withstanding Voltage: 1,000VAC
- Wattage Options: 3W, 5W, 7W, 10W, 15W
- Resistance Range: 180Ω to 33KΩ
- Series: TUM
- Construction: Metal oxide and wirewound types
- Flammability: Inorganic, flameproof
- Overload Capacity: 5x rated power for 5 seconds (TUM series)
- Dimensions: Length approximately 35mm, width 7mm, height 3mm
- Temperature Range: -55°C to +175°C
- RoHS compliant
Buy the Ohmite TUM5J10KE – Reliable Ceramic Power Resistor for Industrial Applications
Discover the high-quality ceramic power resistor designed for demanding industrial environments. With power ratings up to 15W and resistance values from 180Ω to 33KΩ, it offers excellent thermal stability and reliable performance. Its inorganic ceramic construction ensures flameproof safety, making it ideal for high-current and high-temperature applications. The resistor features precise tolerance levels, dielectric withstand capacity of 1,000VAC, and complies with RoHS standards. Efficient and durable, this resistor is perfect for any industrial automation or power circuits needing robust load handling.
Get Ohmite TUM5J10KE today—built for precision, durability, and high-current stability in industrial settings.
Frequently Asked Questions
Where can I buy Ohmite TUM5J10KE?
You can click on the BUY or RFQ button to purchase TUM5J10KE from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part TUM5J10KE?
You can download the TUM5J10KE datasheet or visit the Ohmite website for support.
Who is the manufacturer of TUM5J10KE?
Ohmite
