OMRON ELECTRONIC COMPONENTS G6QE1ADC5 Power Relay
The G6QE1ADC5 is a compact, high-capacity PCB power relay designed for power load switching applications such as air conditioning compressors and power supplies. It features a single-pole configuration capable of switching 32A at 250 VAC resistive load, with a miniature size and low height for easy mounting. Rated for up to 50,000 operations at 40°C, it has achieved a 10-kV impulse withstand voltage between coil and contacts, ensuring high reliability and safety. This relay conforms to cULus, EN, CQC standards, and RoHS compliance, making it suitable for various industrial and home automation uses.
OMRON ELECTRONIC COMPONENTS G6QE1ADC5 Power Relay Specifications:
- Contact Rating: 32 A at 250 VAC resistive load
- Max. Switching Voltage: AC 277 V
- Rated Operate Voltage: 5, 12, 24 VDC
- Coil Resistance: 17.92 Ω at 5 VDC, 102.90 Ω at 12 VDC
- Power Consumption: Approx. 1400 mW at 5 VDC, Approx. 172 mW at 24 VDC (holding voltage)
- Operation Time: 20 ms max.
- Release Time: 10 ms max.
- Insulation Resistance: 1000 MΩ min.
- Impulse withstand voltage: 10 kV between coil and contacts
- Ambient Operating Temperature: -40°C to +85°C
- Dimensions: Height 16 mm, Width 30.5 mm, Depth 20.5 mm
- Standards: RoHS, cULus, EN, CQC
- Number of Operations: up to 50,000 at 40°C
- Electrical Durability: 100,000 operations min.
- Dielectric Strength: 2000 VAC between contacts
Buy the Buy OMRON G6QE1ADC5 Part Number G6QE1ADC5 Online
Purchase the OMRON G6QE1ADC5 power relay online today for reliable power switching in industrial and automation applications. This compact relay features a high switching capacity of 32A at 250 VAC, with excellent impulse withstand voltage of 10 kV between coil and contacts, ensuring operational safety. It is RoHS compliant, cULus, EN, and CQC certified, offering durability for up to 50,000 cycles at 40°C. Ideal for air conditioning, power supplies, and control systems, it ensures dependable performance and easy installation.
Get OMRON G6QE1ADC5 today—built for power switching and long-lasting reliability.
