OMRON ELECTRONIC COMPONENTS XW4M32D2H1DA Push-in Terminal Connector
The product is a 3.5mm-pitch push-in terminal block connector designed for PCB wiring. It features easy insertion and removal with high contact reliability. Compatible with reflow mounting and RoHS compliant, it performs well under temperatures from -40°C to 100°C. Suitable for solid and stranded wires within cross sections of 0.2 mm² to 1.5 mm², and rated for 300V. The connector employs tin and gold plating on contacts, with a durable polyamide housing. Ideal for automation and electronic device wiring, ensuring secure, reliable connections in compact spaces.
OMRON ELECTRONIC COMPONENTS XW4M32D2H1DA Push-in Terminal Connector Specifications:
- Pitch: 3.5mm
- Rated voltage: 300V
- Rated current: 10A
- Wire cross section: 0.2 mm² to 1.5 mm²
- Applicable wire type: solid and stranded with ferrule or without
- Insertion/removal durability: 100 times
- Operating temperature range: -40°C to 100°C
- Housing material: PA (UL94 V-0)
- Contact plating: Tin and gold options
- Cross section of wire with ferrule: 0.25mm² to 0.75mm²
- Dimensions: Refer to CAD data (approximate top view dimensions)
- Certification: UL (File No.E245101), RoHS compliant
- Withstand voltage: 1,600 VAC for 1 minute
- Applicable tools: Flat-blade screwdriver, crimping tools
- Environmental conditions: Humidity 5-85%RH, storage temperature -40°C to 70°C
Buy the Omron Series 3.5mm-Pitch Push-In Connector: XW4M32D2H1DA
Enhance your electronic and automation projects with the reliable Omron push-in terminal connector. Designed for secure, high-quality connections on PCBs, it enables quick wiring and disconnection, reducing assembly time. Its RoHS compliance ensures environmental safety. With robust contact plating options and a durable housing, this connector withstands demanding industrial conditions. Ideal for engineers, technicians, and system integrators, it guarantees durable performance, easy installation, and maintenance, making it a smart choice for efficient and reliable wiring solutions online.
Buy Omron XW4M32D2H1DA now and experience unmatched reliability and performance in PCB wiring and automation systems.
Frequently Asked Questions
Where can I buy OMRON ELECTRONIC COMPONENTS XW4M32D2H1DA?
You can click on the BUY or RFQ button to purchase XW4M32D2H1DA from an authorized OMRON ELECTRONIC COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part XW4M32D2H1DA?
You can download the XW4M32D2H1DA datasheet or visit the OMRON ELECTRONIC COMPONENTS website for support.
Who is the manufacturer of XW4M32D2H1DA?
OMRON ELECTRONIC COMPONENTS
