OMRON A162NRN Industrial Pushbutton Switch
The A16-P pushbutton switch is a detachable, cylindrical switch available in lighted and non-lighted models, suitable for industrial applications. It features high heat-resistant resin levers for easy dip soldering, compact profile width of 28.3 mm, and panel mounting ease. With IP40 and IP66 options, it offers reliable operation with UL, cUL, and IEC certifications, rated for resistive loads up to 3A at 30 VDC and 5A at 125 VAC. Its robust construction ensures durability for demanding environments, making it ideal for control panels, automation systems, and machinery.
OMRON A162NRN Industrial Pushbutton Switch Specifications:
- Operating force: max 4.41N (IP40), max 4.91N (IP66)
- Release force: min 0.29N
- Total travel: approx. 3mm
- Pretravel: max 2.5mm
- Lock travel (alternate operation): min 0.5mm
- Rated voltage: 125 VAC, 250 VAC, 30 VDC
- Current rating: 3A at 30 VDC, 5A at 125 VAC
- Material: High heat resistant resin for lever and terminal
- Contact resistance: max 100mΩ
- Dielectric strength: 2000VAC, 50/60Hz for 1 minute
- Insulation resistance: min 100MΩ at 500VDC
- Temperature range: -10°C to +55°C
- Humidity: 35% to 85%RH
- Standards: UL, cUL, IEC (EN 60947-5-1)
Buy the Omron A16-P – Reliable Industrial Pushbutton Switch for Control Panels
Enhance your automation systems with the robust Omron A16-P pushbutton switch. Available in lighted and non-lighted versions, it features high heat resistance, compact design, and IP66/IP40 protection ratings. Easy to install with panel and PCB mounting, it is suitable for demanding environments requiring reliable operation. Certified for safety and durability, this switch is perfect for control panels, machinery, and automation equipment, ensuring high performance and safety for industrial applications. Order online today for quick delivery and superior quality.
Buy Omron A16-P pushbutton switch now and experience unmatched reliability and performance in industrial control applications.
Frequently Asked Questions
Where can I buy OMRON A162NRN?
You can click on the BUY or RFQ button to purchase A162NRN from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part A162NRN?
You can download the A162NRN datasheet or visit the OMRON website for support.
Who is the manufacturer of A162NRN?
OMRON
