OMRON D2AWA053DR Sealed Switch
The Sealed Ultra Subminiature Basic Switch is a compact, reliable switch designed for high-insulation and sealed environments. It features a long stroke seal, twin clipping contacts for double reliability, and quiet operation, making it ideal for automotive and industrial applications. The switch offers various mounting options, contact forms, and actuator types, with ratings up to 0.1 A at 12 VDC. Its IP67-rated protection ensures durability against dust and water ingress, and it supports mechanical and electrical life cycles up to 200,000 operations, suitable for harsh environments.
OMRON D2AWA053DR Sealed Switch Specifications:
- Degree of protection: IP67
- Contact Material: Silver Plated
- Rating voltage resistive load: 12 VDC 0.1 A
- Insulation Resistance: 100 MQ min. at 500 VDC
- Contact Resistance: 100 mΩ max.
- Dielectric Strength: 1,500 VAC min. between terminals and ground
- Operating Speed: 30 mm to 500 mm/s
- Mechanical life: 200,000 operations min.
- Electrical life: 200,000 operations min.
- Operating Temperature: -40 to 85°C
- Weight: Approx. 0.7 g (pin plunger models with terminals)
Buy the Buy OMROM Sealed Ultra Subminiature Basic Switch Part Number D2AWA053DR Online
Purchase the OMROM Sealed Compact Switch online today and benefit from its high waterproof rating, dual contact system, and versatile mounting options. With an IP67 rating, it withstands dust and water ingress, making it suitable for harsh environments. Designed for long-term durability, this switch supports up to 200,000 mechanical and electrical operations, ensuring your equipment continues to operate smoothly. Flexible actuator choices and easy installation make it ideal for industrial automation, automotive, and safety systems. Get yours now for reliable performance!
Order your OMROM SeriesD2AWA053DR waterproof switch today and ensure premium reliability for your industrial or automotive projects.
Frequently Asked Questions
Where can I buy OMRON D2AWA053DR?
You can click on the BUY or RFQ button to purchase D2AWA053DR from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part D2AWA053DR?
You can download the D2AWA053DR datasheet or visit the OMRON website for support.
Who is the manufacturer of D2AWA053DR?
OMRON
