OMRON D2AWER082DR Sealed Micro Switch
The Sealed Ultra Subminiature Basic Switch, model D2AWER082DR, is designed for high reliability and insulation performance in industrial applications. It features a sealed structure with IP67 protection, suitable for harsh environments. The switch offers multiple actuator options, including pin, leaf lever, simulated roller, and long leaf lever, along with various mounting configurations such as screw-mounted, PCB, and solder terminals. It has a resistive load rating of 0.1 A at 12 VDC, low contact resistance, and excellent dielectric strength, making it ideal for automated and safety-critical systems.
OMRON D2AWER082DR Sealed Micro Switch Specifications:
- Degree of protection: IP67 (waterproof and dustproof)
- Contact Material: Silver plated
- Rating voltage: 12 VDC, Resistive load: 0.1 A
- Dielectric strength: 1,500 VAC min.
- Insulation resistance: 100 MQ min. (at 500 VDC)
- Operating speed: 30 mm to 500 mm/s
- Mechanical operation: 30 operations/min max.
- Electrical operation: 20 operations/min max.
- Operating temperature: -40 to 85°C
- Weight: Approx. 0.7 g (pin plunger models with terminals)
- Vibration resistance: malfunction 10-55 Hz, 1.5mm double amplitude; destruction 1,000 m/s²
- Shock resistance: malfunction 300 m/s², mechanical 200,000 ops min.
- Mounting options include screw, PCB, and solder terminals with various actuator configurations.
Buy the Omron D2AW– Reliable Sealed Switch for Industrial Applications
Enhance your automation systems with the Omron D2AW series sealed micro switch, offering IP67 waterproofing, high insulation, and a variety of actuators and mounting options. Designed for industrial use, this switch ensures durability and reliable performance in harsh environments. Easy to install with screw, PCB, or solder terminals, it has a resistive load capacity of 0.1 A at 12 VDC. Perfect for safety-critical and automation applications, buy online now for quick delivery and trusted quality.
Order your Omron Series D2AW switch today and secure reliable operation in your automation and industrial projects.
Frequently Asked Questions
Where can I buy OMRON D2AWER082DR?
You can click on the BUY or RFQ button to purchase D2AWER082DR from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part D2AWER082DR?
You can download the D2AWER082DR datasheet or visit the OMRON website for support.
Who is the manufacturer of D2AWER082DR?
OMRON
