OMRON D3V161C5 Basic Switch
This miniature snap action switch features a round plunger actuator and is designed for base mounting. It operates with an on-moment switching function, with a single-pole double-throw (SPDT) circuit configuration, and can handle contact currents up to 16 amps. Conforming to EN61058-1 and UL1054 standards, it offers various actuator options including hinge and roller levers, with high-temperature models rated up to 200°C. Its self-cleaning contacts ensure reliable operation in industrial applications, suitable for control panels, automation systems, and safety devices.
OMRON D3V161C5 Basic Switch Specifications:
- Contact Form: SPDT
- Rated Voltage: 250 VAC
- Contact Current: Up to 16 A
- Contact resistance: 30-50 milliohms
- Operating Force: 50 to 200 gf depending on model
- Operating Speed: 0.1 mm to 1 mm
- Insulation Resistance: 100 Megaohms at 500 VDC
- Dielectric Strength: 1000 VAC between terminals
- Temperature Ratings: Up to 200°C for high-temp models, 155°C for others
- Contact Material: Silver alloy or gold alloy
- Contact Gap: 0.5 mm to 1.0 mm
- Terminals: Solder or quick-connect options
- Vibration Resistance: 10-55 Hz, 1.5 mm amplitude
- Shock Resistance: 40G destruction, 10G malfunction
- Life Expectancy: Mechanical 10 million cycles, electrical varies by model
- Degree of Protection: IP40
- Approvals: UL, CSA, EN61058-1
- RoHS Compliant
Buy the Omron Series D3V Reliable Basic Switch Part Number D3V161C5
Purchase the Omron Basic Switch today online—engineered for high reliability and precise control in industrial equipment. With a robust design supporting up to 16A contact current and conforming to industry standards, this switch ensures dependable operation in automation, manufacturing, and safety systems. Its various actuator options, including hinges and rollers, facilitate versatile installation in challenging environments. Designed for durability and performance, buy now and enhance your control panel or machinery with a trusted solution. Fast shipping and secure checkout available.
Get Omron D3V today—built for precision and long-lasting durability in industrial control systems.
Frequently Asked Questions
Where can I buy OMRON D3V161C5?
You can click on the BUY or RFQ button to purchase D3V161C5 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part D3V161C5?
You can download the D3V161C5 datasheet or visit the OMRON website for support.
Who is the manufacturer of D3V161C5?
OMRON
