OMRON D3V162A5H Miniature Basic Switch
The D3V162A5H is a miniature basic switch designed with reliable self-cleaning contacts, available in various models with ratings up to 21 A at 250 VAC. It features an external lever actuator for easy operation, with solder or quick-connect terminals, and complies with RoHS standards. Ideal for precise control in automation and industrial applications, this switch offers excellent electrical durability, multiple actuator options including hinge and roller levers, and a compact, robust construction suitable for mounting in restricted spaces. Its high-quality design ensures long service life and dependable performance under diverse environmental conditions.
OMRON D3V162A5H Miniature Basic Switch Specifications:
- Ratings: 21 A at 250 VAC, 16 A at 250 VAC, 11 A at 250 VAC, 6 A at 250 VAC, 0.1 A at 125 VAC
- Contact form: SPDT (Single Pole Double Throw)
- Contact gap: 1 mm (F gap) or 0.5 mm (G gap)
- Actuator options include pin plunger, short hinge lever, hinge lever, long hinge lever, and roller levers
- Terminals: Solder terminals, quick-connect terminals (#187, #250)
- Mounting hole diameter: 3.1 mm or 2.9 mm (with added '-K' suffix)
- Maximum operating force: 1.23 N (125 gf) for models with standard actuators
- Operating temperature range: -25°C to +85°C (up to +105°C for specific models)
- Insulation resistance: 100 MΩ minimum at 500 VDC
- Dielectric strength: 2000 VAC for 1 minute
- Durability: Mechanical 10 million cycles, electrical 50,000 cycles
- Certifications: UL and CSA approved
- Dimensions: Refer to detailed technical drawings for size specifics
Buy the DEA Series Basic Switch: D3V162A5H
Enhance your automation systems with the DEA Series Miniature Basic Switch, featuring high current ratings, multiple actuator options, and RoHS compliance. Designed for precise control in industrial settings, this switch offers reliable self-cleaning contacts, robust construction, and easy mounting with solder or quick-connect terminals. Its durable design ensures long-term operation under demanding conditions, making it perfect for machinery, automation, and control panels. Purchase online now to guarantee seamless installation and consistent performance for your technical projects.
Order your DEA Series D3V162A5H today and give your projects the dependable quality they deserve with this versatile, high-performance miniature switch.
Frequently Asked Questions
Where can I buy OMRON D3V162A5H?
You can click on the BUY or RFQ button to purchase D3V162A5H from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part D3V162A5H?
You can download the D3V162A5H datasheet or visit the OMRON website for support.
Who is the manufacturer of D3V162A5H?
OMRON
