OMRON D6FCABLE1 Flow Sensor
The MEMS flow sensor provides high-accuracy detection of gas and liquid flow rates up to 50 L/min in compact, RoHS-compliant body designs. Suitable for applications requiring precise measurement, it features various connection options, including three-pin connectors and multiple threaded flow ports for gases like air and natural gas. With a power supply of 10.8 to 26.4 VDC and low current consumption, it offers reliable output voltages from 1 to 5 VDC. Its robust construction supports pressures up to 500 kPa, operating accurately across a temperature range of -10°C to 60°C. Ideal for industrial and automation systems requiring accurate flow sensing.
OMRON D6FCABLE1 Flow Sensor Specifications:
- Flow Range: 0 to 10 L/min, 0 to 20 L/min, 0 to 50 L/min depending on model
- Flow Port Type: Manifold, NPT, Re 1/4, 1/8, 1/2 thread options
- Applicable Gases: Air, Natural gas (13A), and other compatible fluids
- Power Supply: 10.8 to 26.4 VDC
- Current Consumption: Max 15 mA at 25°C
- Output Voltage: 1 to 5 VDC non-linear, load resistance 10 kΩ minimum
- Accuracy: ±3% FS at 25°C
- Repeatability: 0.3% FS
- Maximum Output Voltage: 5.7 VDC
- Rated Power Supply Voltage: 26.4 VDC
- Material: PPS/aluminum alloy case
- Protection Level: IEC IP40 excluding tubing sections
- Withstand Pressure: 500 kPa
- Temperature Range: -10°C to 60°C
- Operating Humidity: 35% to 85%
- Storage Temperature: -10°C to 80°C
- Storage Humidity: 35% to 85%
- Dimensions: Approximately 30 x 78 x 30 mm
- Weight: 103 grams
Buy the Buy SES MEMS Flow Sensor Part Number D6F-50A6-000 Online
Order the SES MEMS Flow Sensor D6F-50A6-000 online today and enjoy reliable, high-precision flow measurement up to 50 liters per minute. Designed with a compact size of approximately 30 x 78 x 30 mm and robust construction, this sensor is ideal for industrial automation, gas flow detection, and fluid monitoring applications. It features a wide operating voltage of 10.8 to 26.4 VDC, low power consumption, and precise output voltage ranging from 1 to 5 VDC. Its IP40 rated case ensures durability in demanding environments, providing accurate readings across a temperature range of -10°C to 60°C.
Get SES MEMS Flow Sensor D6F-50A6-000 today—built for precision and long-lasting durability in flow measurement.
Frequently Asked Questions
Where can I buy OMRON D6FCABLE1?
You can click on the BUY or RFQ button to purchase D6FCABLE1 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part D6FCABLE1?
You can download the D6FCABLE1 datasheet or visit the OMRON website for support.
Who is the manufacturer of D6FCABLE1?
OMRON
