OMRON EESX1096 Transmissive Optical Sensor
The EE-SX1081 is a high-resolution transmissive optical sensor featuring a 5-mm-wide slot, PCB mounting design, and a 0.5-mm aperture for precise detection. It operates within a temperature range of -25°C to 85°C, with an emitter forward current of 50 mA and collector current of 20 mA. The sensor offers a collector-emitter voltage of 30V, quick response times, and low dark current, making it ideal for precise object detection in automation and industrial applications. Its compact size and high performance ensure reliable operation in various environments.
OMRON EESX1096 Transmissive Optical Sensor Specifications:
- Dimensions: 3mm max. width, terminal No. A (3cmm+0.3 mm), K (10<mm+0.55 mm), E (18<mm+0.65 mm)
- Operating Temperature: -25°C to 85°C
- Emitter Forward Voltage: 1.2 V typical, 1.5 V max at 30 mA
- Collector-Emitter Voltage: 30 V
- Collector Current: 20 mA
- Dark Current: 2 nA typical, 200 nA max
- Pulse Forward Current: 1 A
- Soldering Temperature: 260°C
- Response Time: 4 μs (typical)
- Wavelength: 940 nm typical
- Operating and Storage Temperature: -30°C to 100°C
Buy the Omron Series Transmissive Optical Sensor: EESX1096
Purchase the Omron EESX1096 transmissive optical sensor online today to enhance your automation system's precision and reliability. Featuring a 5-mm-wide slot and a 0.5-mm aperture, this PCB-mounted sensor offers fast response times, low dark current, and a broad temperature range from -25°C to 85°C. Its compact design ensures easy integration into various industrial applications, providing accurate detection and consistent performance. Order now and improve your automation process with trusted technology tailored for demanding environments.
Buy Omron EESX1096 now and experience unmatched reliability and high-precision object detection for industrial automation.
Frequently Asked Questions
Where can I buy OMRON EESX1096?
You can click on the BUY or RFQ button to purchase EESX1096 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part EESX1096?
You can download the EESX1096 datasheet or visit the OMRON website for support.
Who is the manufacturer of EESX1096?
OMRON
