OMRON G2R24DC24 Power PCB Relay
This general-purpose relay features a 24 V DC coil and a DPDT contact configuration capable of handling up to 5A. Designed for PCB mounting, it operates as a stable switch suitable for various industrial applications requiring reliable switching. The relay's construction ensures high stability, with a creepage distance of 8.0 mm minimum between coil and contact, and safety features supporting high surge resistance of 10,000 V. Ideal for automation, control systems, and equipment that demand durability and precise operation in challenging environments.
OMRON G2R24DC24 Power PCB Relay Specifications:
- Coil Voltage: 24 V DC
- Contact Configuration: DPDT (double-pole double-throw)
- Maximum Load: 5A
- Contact Material: Silver Alloy
- Maximum Switching Capacity: 1,250 VA, 150 W
- Operate Time: Max. 20 ms
- Release Time: Max. 20 ms
- Bounce Time: Approx. 3 ms (operate), Approx. 8 ms (release)
- Insulation Resistance: 1,000 MΩ at 500 VDC
- Dielectric Strength: 5,000 VAC for 1 min between coil and contacts
- Ambient Temperature Range: -40 to 70°C
- Vibration Resistance: Mechanical 10-55 Hz; 1.50 mm double amplitude
- Shock Resistance: Mechanical 1,000 m/s² (approx. 100 G)
- Service Life: Mechanical 10 million operations min., Electrical 100,000 operations
Buy the Omron G2R24DC24 – Reliable Power PCB Relay for Industrial Applications
Get the Omron G2R24DC24 power PCB relay now available online. With a 24 V DC coil and 5A switching capacity, this DPDT relay is perfect for automation and control systems. Designed for PCB mounting, it offers high surge resistance, stability, and long service life. Ideal for manufacturing, industrial automation, and equipment requiring reliable switching in harsh environments. Purchase today to enhance your project's performance with trusted Omron quality and quick delivery options.
Order your Omron G2R24DC24 industrial relay today and ensure your control systems operate with dependable switching performance and high durability.
Frequently Asked Questions
Where can I buy OMRON G2R24DC24?
You can click on the BUY or RFQ button to purchase G2R24DC24 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part G2R24DC24?
You can download the G2R24DC24 datasheet or visit the OMRON website for support.
Who is the manufacturer of G2R24DC24?
OMRON
