OMRON G2RL1AHDC5 PCB Relay
The G2RL series is a high-performance PCB relay designed for industrial control applications, featuring various models with high sensitivity, high capacity, and fully sealed options. It conforms to VDE EN61810-1, UL recognized, and CSA certified, ensuring reliable safety standards. Suitable for HVAC, motor control, and household products, it offers flexible contact configurations: SPST-NO, SPDT, DPST-NO, and DPDT. Coils operate efficiently across voltage ranges with low power consumption, and contact ratings reach up to 16 A. Dimensions and mounting options enable easy integration in compact, demanding environments. It provides excellent insulation resistance, dielectric strength, and endurance, making it ideal for reliable automation systems.
OMRON G2RL1AHDC5 PCB Relay Specifications:
- Coil Voltage: 3-48 VDC with ratings at 5, 12, 24, 48 VDC
- Rated Coil Current: 16.7 mA to 80.0 mA depending on voltage
- Coil Resistance: 1,440 to 5,358 Ohms
- Contact Ratings: Up to 16 A at 250 VAC, 10 A at 24 VDC
- Max switching voltage: 440 VAC, 300 VDC
- Max switching power: 3,000 VA to 4,000 VA
- Insulation Resistance: ≥ 1,000 MΩ at 500 VDC
- Dielectric Strength: 5,000 VAC between coil and contacts
- Endurance: Up to 20 million operations mechanical
- Operating Temperature: -40°C to 85°C
- Dimensions: Approximate length 29 mm, width 15.7 mm, height varies by model
- Weight: Approx. 12 g
- Standards: UL Recognized, CSA Certified, CE to EN61810-1, RoHS Compliant
- Configuration Options: SPST-NO, SPDT, DPST-NO, DPDT; Fully sealed or flux protection versions
- Tracking Resistance: CT > 250
- Clearance and Creepage Distance: 10 mm/10 mm
- Material: Silver alloy contacts, Class F coil insulation system
Buy the Omron Series G2RL PCB Relay: G2RL1AHDC5
Order the Omron G2RL1AHDC5 PCB relay online today to ensure dependable performance in HVAC, motor, and automation control systems. Featuring high capacity current ratings up to 16 A, various contact configurations, fully sealed options, UL and CSA certification, and RoHS compliance, this relay offers exceptional durability, insulation resistance, dielectric strength, and long-lasting mechanical endurance. Its compact size facilitates easy integration into control panels and automation systems. With excellent electrical characteristics, low power consumption, and adherence to safety standards, purchase online now for prompt delivery and reliable operation in your control applications.
Get Omron G2RL1AHDC5 today—designed for reliable control, high current capacity, and easy PCB mounting for industrial automation.
Frequently Asked Questions
Where can I buy OMRON G2RL1AHDC5?
You can click on the BUY or RFQ button to purchase G2RL1AHDC5 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part G2RL1AHDC5?
You can download the G2RL1AHDC5 datasheet or visit the OMRON website for support.
Who is the manufacturer of G2RL1AHDC5?
OMRON
