OMRON G2RL2DC6 PCB Power Relay
The G2RL PCB Power Relay is a low-profile, high-capacity electronic switch designed for miniature equipment. It features a maximum height of 15.7 mm, conforms to UL508, CSA22.2, IEC/EN 60335-1 standards, and offers various contact configurations such as SPST-NO, SPDT, and DPST-NO with ratings up to 16 A at 250 VAC. Suitable for industrial machinery and home appliances, it has flux protection, coil insulation system Class F, and operates at ambient temperatures up to 105°C. It ensures reliability with high switching capacity and meets multiple safety certifications.
OMRON G2RL2DC6 PCB Power Relay Specifications:
- Height: 15.7 mm maximum
- Contact Ratings: up to 16 A at 250 VAC, 12 A at 24 VDC
- Contact Materials: Silver alloy (Cd free)
- Insulation System: Class F
- Standards: UL508, CSA22.2, IEC/EN 60335-1, VDE (EN61810-1)
- Ambient Operating Temperature: -40°C to 105°C
- Creepage and Clearance Distance: Minimum 8 mm
- Coil Resistance: Measured at 23°C with ±10% tolerance
- Power Consumption: Approx. 400 mW at rated voltage, approx. 100 mW at holding voltage
- Durability: Mechanical operations up to 720 million with proper conditions
- Dimensions: 18.7 mm max width, 35 mm length, PCB mounting holes, terminal layout specified
- Certifications: UL Recognized, CSA Certified, CE, RoHS compliant
- Shock Resistance: 4,000 m/s², endurance tested
- Electrical Endurance: Up to 400,000 operations at rated voltage
- Temperature Range: -40°C to 105°C depending on model
- Approval Ratings: UL, CSA, IEC/EN standards
- Sealing: Sealed models available with flux resistance
- Application: Industrial machinery, automation systems, home appliances
Buy the Buy Omron G2RL PCB Power Relay Part Number G2RL2DC6 Online
Purchase the Omron G2RL series PCB Power Relay online today to secure a high-capacity, low-profile relay that meets international safety standards. Perfect for industrial machinery, automation systems, and home appliances, the relay offers a compact design with ratings up to 16 A at 250 VAC, ensuring dependable switching performance. Its flux protection and sealed options make it suitable for harsh environments, while the UL, CSA, and IEC certifications guarantee quality and safety. Simplify your procurement and ensure operational reliability by ordering online now.
Order your Omron Series G2RL PCB Power Relay G2RL2DC6 today and ensure reliable switching performance in your industrial or home automation projects.
Frequently Asked Questions
Where can I buy OMRON G2RL2DC6?
You can click on the BUY or RFQ button to purchase G2RL2DC6 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part G2RL2DC6?
You can download the G2RL2DC6 datasheet or visit the OMRON website for support.
Who is the manufacturer of G2RL2DC6?
OMRON
