OMRON G4A1AEDC24 Power Relay
This miniature power relay features a PCB mount design with quick connect terminals, supporting 20 Amp switching current at 250 VAC. It includes a 24 VDC coil, SPST normally open configuration, and conforms to UL, CSA, and EN standards for creepage distance. The relay employs high noise-resistant insulation materials, ensuring long-lasting performance. It supports a maximum switching power of 5,000 VA and has a coil power consumption of approximately 0.9 W. Ideal for motor switching and various industrial automation applications, it provides reliable electrical operation under demanding conditions.
OMRON G4A1AEDC24 Power Relay Specifications:
- Coil Rating: 24 VDC
- Rated current: 75 mA
- Coil resistance: 1602 Ω
- Max. Switching Voltage: 250 VAC
- Max. Switching Current: 20 A
- Max. Switching Power: 5,000 VA
- Contact Resistance: 100 mΩ max.
- Operate Time: 20 ms max.
- Release Time: 10 ms max.
- Insulation Resistance: 1000 MΩ at 500 VDC
- Dielectric Strength: 4,500 VAC between coil and contacts
- Ambient Temperature: -20°C to 60°C
- Weight: Approx. 25 g
- Endurance: Mechanical 2,000,000 operations; Electrical 30,000 operations
Buy the Buy Omron G4A1AEDC24 Power Relay Part Number G4A1AEDC24 Online
Order the Omron G4A1AEDC24 power relay online today to ensure your automation system runs smoothly. This compact relay supports 20A switching at 250VAC, with a 24V DC coil, and features a robust SPST configuration. Its high insulation and compliance with UL, CSA, and EN standards guarantee safety and durability in demanding industrial environments. Easy to install with quick connect terminals, it offers long operational life with high endurance, making it an excellent choice for motor control, automation, and switching applications. Buy now for fast delivery and seamless integration into your systems.
Buy Omron G4A1AEDC24 power relay now and experience reliable switching for industrial automation and motor control applications.
Frequently Asked Questions
Where can I buy OMRON G4A1AEDC24?
You can click on the BUY or RFQ button to purchase G4A1AEDC24 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part G4A1AEDC24?
You can download the G4A1AEDC24 datasheet or visit the OMRON website for support.
Who is the manufacturer of G4A1AEDC24?
OMRON
